Richelieu 4025180 40mm Piano HingeRichelieu 4025180 Piano Hinge - Width 40 mm offers a robust solution for various applications, combining strength and versatility in a sleek design. Originally designed for piano lids, this continuous hinge is now ideal for cabinets, storage boxes, outdoor sheds, and more heavy-duty utilities like fire doors and security deposit boxes. Constructed from durable steel with a nickel finish, this hinge measures 82 feet in length and features a fixed pin design. The hinge is 1 9/16 inches wide and has a thickness of 1/32 inch, ensuring it can withstand demanding environments. With a center-to-center drilling of 2 3/8 inches, installation is straightforward, utilizing #5 screws for secure fastening. Richelieu's piano hinge is not only cost-effective but also meets the rigorous needs of a variety of industries, including agriculture, construction, and marine applications. Its waterproof and rust-resistant properties make it suitable for use in large ocean vessels and sailboats. Whether you're working on trailers, appliances, or laboratory equipment, this hinge provides reliable performance and ease of installation. Elevate your projects with the Richelieu 4025180 Piano Hinge, engineered to deliver strength and functionality where you need it most.
Piano Hinge - Width 40 mm
Piano hinges, or continuous hinges, found their name from their original purpose, piano lids. They are now used in various everyday wood and metal made utilities like chests, foldable doors, trunks, safes or in more heavy-duty utilities like shed/barn doors or fire doors. This type of hinge is made with only 3 three components, which makes it simple to use and install. The load capacity of this type of hinge is unfortunately very difficult to calculate and is mostly dictated by the material used, the thickness of the hinge and the pin diameter. On the other hand they can meet the most demanding needs if chosen carefully.
Piano hinges are a very strong and cost effective way to conduct your different type of project. They can meet the most demanding needs if chosen carefully.
- Made in Canada
Application
- Cabinets, storage boxes & outdoor sheds
- Aluminum shower doors
- Display booths
- Security deposit boxes
- Money-counter machines
- Trailers/campers/mobile homes
- Waste containers
- Casino and arcade machines
- Agriculture, construction and airline equipment
- Large ocean vessels/sail boats (salt, rust and water-proof)
- Appliances
- Laboratory and medical equipment
Attributes
Ship via: No UPS - Common Carrier Only
Center to Center Drilling: 60 mm
Color/ Finish: Nickel
Fastener: #5 Screw
Finish: Nickel
Length: 25 m
Material: Steel
Packaging format: Per unit
Pin: Fixed Pin
Product #: 4025180
Product number: 4025180
Product №: 4025180
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Thickness: 0.8 mm
Type: With Holes
Unit 1: case - 5
Width: 40 mm
