Adams Rite 2190-322-2MD-10B Deadbolt/Deadlatch, Oil Rubbed Bronze
The Dual Force 2190 Interconnected Deadbolt/Deadlatch provides access control and security for aluminum stile doors. Latch and deadbolt capabilities are combined for fast, easy, and panic-proof exiting.
Function
The Dual Force 2190 combines the access control capabilities of a latch with the security of a deadbolt. The key retracts and extends the deadbolt (and deadlatch) from either side. The exterior lever retracts the latch only, while the inside lever retracts the deadbolt and latch simultaneously for fast, easy, panic-proof exiting. Intended for out-swinging doors.
Opetation
Key or thumbturn retracts or extends deadbolt or deadlatch. Inside lever retracts both when configured with interconnect feature. Outside lever retracts latch only. Latch holdback feature activated or deactivated by turning key to retract latch and sliding holdback button on faceplate down to hold and up to release. 2190 will not work without its specially designed strike - included standard in package.
Dead latches are the suitable solution to any door system that requires free operation from the interior at all times but access from the exterior only at certain times. Adams Rite has been working with commercial applications like these for decades and offers a range of dead latches to accommodate any situation.
The Adams Rite electrified dead latch set It perfectly combines non-handed, narrow backset, mechanical locking hardware with electronic access control. The set can be used with a timer or operated manually.
Other death latches range from the standard duty to the heavy duty death latch in American National Standards Institute (ANSI) size. The heavy duty deal latches are solid brass with a stainless steel auxiliary latchpin. The standard duty death latches feature hardened steel internal pins and an all metal auxiliary latchpin.
All Adams Rite dead latches feature a bolt holdback feature that allows a reverse turn of the key to retain the bolt, allowing the door to operate as free swinging, typically during business hours.
With a variety of sizes and trim packages, you will be able to get the right dead latch for any existing door or new door installation.
Oil Rubbed Bronze
We carry the Adams Rite line of electrical locks for aluminum doors and glass door locks because they are absolutely unsurpassed. Adams Rite dominates the market for aluminum door electromechanical locks and locking systems.
The company introduced the Maximum Security lock in 1955, and it still remains a major choice for applications where it is suitable. Adams Rite has created numerous locks for this market since that time.
Adams Rite is a subsidiary of ASSA ABLOY and shares that owner’s pedigree for outstanding products, service and innovation. We are very proud of our relationship with this company because they care about meeting your needs as much as we do.
This care is evident in the RITE Door integrated door assembly. This remarkable product has been installed in healthcare, education and commercial applications because of it provides clean sight lines and low profile hardware.
The innovation that is a company hallmark is evident in their line of products designed to covert aluminum and glass storefronts to electrified openings. This improves the safety and security of the business.
Take some time and explore the electrical locks for aluminum doors and the glass door locks available through Adams Rite. You are certain to find what you need for any situation.
Product category: Deadlocks
Dimensions: Field-selectable inter-connection feature allows interior trim to retract deadbolt and deadlatch. Consult local building officials for guidance in code compliance. Retrofits to existing MS1850S Deadbolt or 4500 and 4900 Deadlatch of the same backset. 1-3/4” minimum door thickness required. Cylinder Backset: 1-1/8” or 1-1/2” only.
Bolt: Latchbolt: 5/8” throw, solid brass. Easily reversible using only a screwdriver. Deadbolt: 1” throw, stainless steel.
Strike: Standard strike furnished is the 2101-01 for flat jamb where door closes flush or nearly flush. The 2101 covers MS® Deadlock strike preparation with modification, and the 4901 Deadlatch strike directly. Also available in radius version for opposite stile pairs of doors and with extended lip strikes for special jamb conditions.
Compatible Products: Extended lip strikes available separately.
