CRL Z610BR Polished Brass Z-Series Square Radius Base Zinc Clamp for 3/8" Glass

Your Price: $29.81

Retail Price:$35.68

Your Savings:$5.87(16%)

The CRL Z610BR Polished Brass Clamp securely holds 3/8" glass for railings and partitions, featuring durable zinc construction.

Part Number : CRL_Z610BR

Availability: 16 In Stock

Quantity

Description

CRL Z610BR Polished Brass Z-Series Square Radius Base Zinc Clamp for 3/8" Glass

C.R. Laurence Z610BR Polished Brass Z-Series Square Type Radius Base Zinc Clamp for 3/8" Glass offers a sleek and durable solution for securing glass in various architectural applications. Designed specifically for 3/8" (10 mm) glass, this clamp is ideal for use on mezzanines, partitions, railings, and windbreaks. Constructed from quality zinc or stainless steel, it ensures longevity and performance in both interior and exterior settings. The Z610BR features a flat base design, making it suitable for square tubing or other flat surfaces. For enhanced stability, a steel pin is included to provide additional glass support, with a required 1/2" (12 mm) hole for installation. If you need replacement gaskets, simply order the CRL Cat. No. Z38SG. Customization options are available with custom painted finishes to match your design needs. With an overall height of 2-9/32" (58 mm) and a width of 2-1/8" (54 mm), the clamp’s polished brass finish adds a touch of elegance to any project. Remember to pin each glass panel as required to prevent slippage, ensuring a secure and professional finish. Elevate your architectural designs with the reliability and style of the CRL Z610BR clamp.

Polished Brass Z-Series Square Type Radius Base Zinc Clamp for 3/8" Glass

For 3/8" (10 mm) Glass
Replacement Gaskets are Available by Ordering Cat. No. Z38SG
For Use on Mezzanines, Partitions, Railings and Windbreaks
Use Monolithic Tempered Glass
Steel Pin Available for Additional Glass Support
Custom Painted Finishes Available Upon Request

This CRL Z-Series Square Type Radius Base Glass Clamp is designed to be used on glass thickness of 3/8" (10 mm). Constructed from either zinc or stainless steel, the clamps are the perfect solution for partitions, railings, windbreaks and countless other projects.

For securing the Z-Clamp to thin wall tubing (less than 1/8"), use CRL’s ZB0LT Socket Head Cap Bolt and ZRNUT Rivet-Nut. For installation, drill a 17/32" (13.5 mm) hole, then install the Rivet-Nut using 34604 Heavy-Duty Thread Insert tool and 34618 5/16" Mandrel and Nosepiece.

NOTE: 1/2" (12 mm) hole is required if using the steel pin (included with the clamp) for additional glass support.

SPECIFICATIONS:
Glass Thicknesses: For 3/8" (10 mm).
Base Design: Flat
For Use With: Square Tubing or Other Flat Surfaces
Material: Choice of Zinc Constructed or Stainless Steel. Stainless Steel or Powder Painted Zinc Clamps are recommended for more durability in exterior applications.
Glass Fabrication:

For 1/4" (6 mm), 5/16" (8 mm), and 3/8" (10 mm) Thick Glass: 1/2" (12 mm) diameter hole required if using provided steel pin for glass support.

For 1/2" (12 mm) Thick Glass: 9/16" (14 mm) diameter hole required if using provided steel pin for glass support.
Includes: Rubber Gaskets (CRL Cat. No. Z38SG) and Steel Pin (for optional use) with Grommet.
Replacement Hardware: CRL ZCS5X5BR for Replacement Screws

Product Warning:

For interior CRL recommends pinning each glass panel as required when the glass is not supported from the bottom edge to prevent glass panel slippage. Rubber gaskets and steel pins are provided with each clamp.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Brass Finish Advisory:

Although durable, brass is prone to oxidation. It can give brass and brass finishes a tarnished look, regardless of how the hardware is initially packaged or stored. For more information, view the Brass Finish Disclaimer found in the Technical References section below.

Attributes

Base Type: Radius

Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov

Depth: 1-3/8 in. (35 mm)

Finish/ Color:: Polished Brass

Glazing Thickness: 3/8 in. (10 mm)

Height: 2-9/32 in. (58 mm)

Material: Zinc

Profile: Square

Shipping Limitations: None

Width: 2-1/8 in. (54 mm)
