When you need a tough, reliable lock for government/military, retail, industrial or multi-family project, you need a Falcon B-Series Lock. Our full line of Grade 2 locksets are a perfect replacement for existing locks, or a smart spec in new construction. With upgraded finishes these locks deliver style as well as strength. Falcon B-Series locks feature an interchangeable core that can be removed for quick, easy re-keying and are compatible with SFIC products from other manufacturers. Most important, they are backed by one of the best names in the industry.
Attributes
Ship via: Can Ship UPS
Ansi Function: F109 - Entry/Office
Ansi Function Description: Entry/Office
Baa Qualified: No
Bolt Protection: 1/2"
Bore Hole Diameter: 2-1/8"
Country of Origin: Mexico
Cylinder Type: SFIC Prep Less Core
Cylinders Present: Single Cylinder
Door Thickness: 1-3/8" to 2"
Finish: 613/US10B
Finish Description: Dark Oxidized Satin Bronze Oil Rubbed
Fire Rated: 3 Hours {A}
Function: B511-Entry/Office Lock
Function Family: Entrance
Grade: Grade 2
Hand: Non-handed
Latch Backset Dim: 2-3/4"
Latch Bore Diameter: 7/8"
Latch Number: A57435-00D
Latch Type: Deadlatch
Lever Knob: Lever
Lever Knob Design: D - Dane
Lever Knob Design Family: Return Lever
Lever Knob Design Name: Dane
Limited Warranty: 10 Year Warranty
Lock Face Size: 1-1/8" x 2-1/4"
Manufacturer Function: Entry/Office Lock
Manufacturer Function Description: Turn/push button locking. Pushing and turning button locks outside lever requiring use of key until button is manually unlocked. Push button locking. Pushing button locks outside lever until unlocked by key or by rotating inside lever. Inside lever always free. Deadlocking latch bolt.
Maximum Door Thickness: 2"
Minimum Door Thickness: 1-3/8"
Num Pins: 7-Jun
Projection: 2-5/8"
Restrictions: No
Rose Escutcheon: Rose
Rose Escutcheon Design: 3-1/2 In. Diameter
Rose Escutcheon Dimensions: 3-1/2"
Screws: Wood/Metal Screws
Series: B Series Grade 2 Cylindrical Lever Locks
Strike Dimensions: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 5164
Strike Type: ASA Strike
Strike Width: 1-1/4"
Structure Cylinder: B
Structure Function: 511
Structure Latch: D
Structure Latch Number: A57435-00D
Structure Outside Finish: 613
Structure Outside Trim: D
Structure Series: B
Structure Strike Number: 5164
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
