Whether your application is government/military, retail, industrial or multi-family, there's a W Series lock that fits perfectly. With two popular lever and knob styles as well as two popular rose diameters (large and small), Falcon W Series can match most commercial door trim. The Falcon W Series locks feature conventional cylinders and small format interchangeable cores that are compatible with SFIC products from other manufacturers. Our conventional cylinders are available in all Falcon conventional key sections as well as Schlage C keyway, which we now masterkey across the complete Falcon product line. The Falcon W Series offers quality product at a value price, and is backed by one of the best names in the business - Allegion.
Attributes
Ship via: Can Ship UPS
Ansi Function: F86 - Storeroom
Ansi Function Description: Storeroom
Baa Qualified: Yes
Bolt Protection: 1/2"
Bore Hole Diameter: 2-1/8"
Country of Origin: Mexico
Cylinder Type: SFIC Prep Less Core
Cylinders Present: Single Cylinder
Door Thickness: 1-3/8" to 1-3/4"
Dust Box: Plastic
Finish: 605/US3
Finish Description: Bright Brass
Fire Rated: 3 Hours {A}
Function: W581-Storeroom Lock
Function Family: Storeroom
Grade: Grade 2
Hand: Non-handed
Latch Backset Dim: 2-3/4"
Latch Bore Diameter: 1"
Latch Number: 30-197
Latch Type: Deadlatch
Lever Knob: Knob
Lever Knob Design: ELI - Elite Knob
Lever Knob Design Family: Bell Knob
Lever Knob Design Name: Elite
Limited Warranty: 10 Year Warranty
Lock Face Size: 1-1/8" x 2-1/4"
Manufacturer Function: Storeroom Lock
Manufacturer Function Description: Deadlocking latch bolt by lever inside or key outside. Outside lever is inoperable. Inside lever always free.
Maximum Door Thickness: 1-3/4"
Minimum Door Thickness: 1-3/8"
Num Pins: 6
Projection: 2-11/16"
Restrictions: None
Rose Escutcheon: Rose
Rose Escutcheon Design: 3-1/2" Rose Diameter
Rose Escutcheon Dimensions: 3-1/2"
Screws: Wood/Metal Screws
Series: W Series Grade 2 Cylindrical Knob Locks
Strike Dimensions: 1-1/4" x 4-7/8"
Strike Height: 4-7/8"
Strike Number: 30-148
Strike Type: ASA Strike
Strike Width: 1-1/4"
Structure Cylinder: B
Structure Function: 581
Structure Latch: D
Structure Latch Number: 30-197
Structure Outside Finish: 605
Structure Outside Trim: ELI
Structure Series: W
Structure Strike Number: 30-148
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
