Ship via: Can Ship UPS
Adjustment: Opening and closing force, opening angle
Color: Silver colored matt
Flap weight: Horizontal 3.2-4.3 Vertical 3.3-4.5
For flap height: 330–380 mm
Installation: For screw fixing with Euro screws
Internal cabinet depth: min. (7 11/16") 196 mm (horizontally), min. (4 5/16") 110 mm (vertically)
Material: Fitting and cover caps: Plastic, front fixing bracket: Zinc alloy
Model: C
Size: Housing: W x L x D: 89 x 23 x 163 mm (3 1/2 x 15/16 x 6 7/16") when installed horizontally
Suitable for: For wooden doors, with adjustable breaking effect and soft open and solft closing mechanism Left or right hand use
