Hafele 909.02.421 Fastener is engineered for seamless installation of pull handles on wooden, metal, and plastic doors with a thickness of 1-3/8 to 1-3/4 inches (35–44 mm). This one-sided fastener features a sleek, matt stainless steel cover cap, ensuring an attractive and modern finish that complements a variety of door styles. Included with the fastener are square spindles and screws specifically designed for the specified door thickness, simplifying the installation process. This model is suitable for straight supports and is compatible with a range of FSB door handles, including models 66 6501, 66 6535, 66 6536, 66 6602, 66 6669, 66 6670, and 66 6681, making it a versatile choice for both residential and commercial applications. Installation is straightforward, requiring one mounting set for each pull handle when affixed on one side. The M8 thread diameter ensures a secure fit, while the durable stainless steel material guarantees longevity and resistance to wear. With the Hafele 909.02.421 Fastener, you can achieve a professional look that enhances the functionality and aesthetics of your doors without compromise.
Fastener, One-Sided for Wood Thickness (1-3/8 - 1-3/4")
Visible, For door thickness: 35–44 mm, cover cap: Stainless steel matte
Square spindles and screws for the specified door thicknesses are supplied with the sets.
Area of application: For ⌀35 mm pull handles
Color/finish: Matt
Door type: Wooden doors, Metal doors, Plastic doors
For door thickness: 35 – 44 mm
For support shape: for straight supports
For wood thickness: 1 3/8 - 1 3/4"
Installation: on one side
Material: Stainless steel
Model: 05 0580 04335 6204
Order reference: One mounting set is required for each pull handle when installed on one side.
Suitable for: FSB door handle, model 66 6501, 66 6535, 66 6536, 66 6602, 66 6669, 66 6670, 66 6681
Supports: for straight supports
Thread diameter (inch): M8
Thread Ø: M8
Version: Cover cap: Stainless steel, matt
