Richelieu 2716637100 FREEflap Mini Lift System is a practical, balanced, and compact solution designed for modern cabinetry. This system stands out in the lifter family as a robust performer, offering an integrated multi-position stop that ensures the door remains securely in any desired position. Suitable for wooden doors ranging from 9 27/32 to 15 3/4 inches in height, the FREEflap Mini is engineered for lift-up opening types, making it ideal for creating sleek, unobtrusive cabinetry. The light gray finish complements a variety of design aesthetics, providing both functionality and style. With a hinge opening angle of +107°, this lift system allows for smooth operation and easy access to contents, enhancing user convenience. The power factor of 1,389 to 2,800 ensures that it can handle various door weights while maintaining performance. This product is part of Richelieu’s System C, known for its reliability and efficiency. The FREEflap Mini is not only a smart choice for builders and designers, but it also ships conveniently via UPS, making it an easy addition to any project. Elevate your cabinetry solutions with the Richelieu FREEflap Mini Lift System, where practicality meets robust design.
FREEflap Mini Lift System
Brand: Richelieu
Door Height: 250 to 400 mm
Door Type: Wood Door
Finish: Gray
Hinge Opening Angle: +107°
Max weight for door height <= to 200 mm: 6.8 to 14.7 kg
Max weight for door height <= to 225 mm: 6 to 13.1 kg
Max weight for door height <= to 250 mm: 5.4 to 11.8 kg
Max weight for door height <= to 275 mm: 4.8 to 10.6 kg
Max weight for door height <= to 300 mm: 4.4 to 9.6 kg
Max weight for door height <= to 325 mm: 4 to 8.8 kg
Max weight for door height <= to 350 mm: 3.7 to 8.1 kg
Max weight for door height <= to 375 mm: 3.5 to 7.5 kg
Max weight for door height <= to 400 mm: 3.2 to 7 kg
Max weight for door height <= to 425 mm: 2.9 to 6.5 kg
Max weight for door height <= to 450 mm: 2.7 to 6.1 kg
Opening Angle: 107°
Opening Types: Lift-Up Opening
Opening Types NEW: Lift-Up Opening
Power Factor: 1 389 to 2 800
Product #: 2716637100
Product number: 2716637100
Product №: 2716637100
System Name: C
System Type: Soft-Close
Unit: Box
Unit 1: skid - 180
Unit 2: skid - 180
