Richelieu 8916605170 R-Exact Sliding Door System offers a stylish and efficient solution for your sliding door needs. Designed for both residential and light-duty office applications, this system features a flat bar running rail with Z-design connecting ends, ensuring smooth and seamless operation. Its pre-drilled fixation points are spaced at 16 inches (406.4 mm) centers, simplifying installation and making it a user-friendly choice for building professionals and savvy homeowners alike. Accommodating door thicknesses ranging from 1 3/8 to 1 25/32 inches, the R-Exact system supports a maximum load capacity of 176 lbs, making it a robust option for various wood door types. With an overall length of 67 7/8 inches and a door width compatibility of 28 to 34 inches, this sliding door hardware is versatile and can adapt to different spaces. The contemporary style and stainless steel finish not only enhance aesthetic appeal but also provide durability. Designed for wall mounting, this system uses upper-position ball bearing rollers for effortless movement. Note that a groove is required for the guiding system, ensuring stability and precision. Elevate your space with the Richelieu R-Exact Sliding Door System-where functionality meets modern design.
R-Exact Sliding Door System
Application: Standard Access Door, Barn Door
Brand: Richelieu
Door Material: Wood
Door Position: In Front of Wall
Door Thickness: 35 to 45 mm
Door Width: 28 to 34 in
Finish: Stainless Steel (170)
Groove Needed for Guiding System: Yes
Length - Overall Dimensions: 67 7/8 in
Load Capacity: Max. 176 lb*
Manufacturing Material: Stainless Steel
Number of Doors: 1
Overall Length: 67 7/8 in
Packaging format: Box
Product #: 8916605170
Product number: 8916605170
Product №: 8916605170
Roller Position: Upper
Roller Type: Ball Bearing
Soft- Closing: No
Style: Contemporary
Track Finish: Stainless Steel
Track Length: 67 7/8 in
Track Material: Stainless Steel
Track Mounting: Wall Mount
Track Type: Flat Bar
Track type: Flat Bar
Unit: Box
Unit 1: case - 4
Unit 2: case - 4
Weight Capacity per Door: Max. 80 kg
