Attributes

Ship via: Can Ship UPS

Ansi Function: F04 - Entry/Office

Baa Qualified: Yes

Bolt Protection: 3/4 In.

Country of Origin: Mexico

Cylinder Type: Less Cylinder

Door Thickness: 1-3/4 In. - 2 In.

Dust Box: Plastic

Finish: 605/US3

Finish Description: Bright Brass

Fire Rated: 3 Hours {A}

Function: 9056-Entrance Office w Auto Unlocking

Function Family: Entrance/Office

Grade: Grade 1

Hand: Field Reversible

Latch Backset Dim: 2-3/4"

Latch Type: Dead Latch (Guarded)

Lever Knob Design: 01 - Lever

Lever Knob Design Family: Straight Lever

Limited Warranty: 3 Years

Lock Face Size: 8 In. x 1-1/4 In.

Manufacturer Function Description: Latchbolt retracted by knob/lever from either side unless outside is made inoperative by key outside or by rotating inside thumbturn. Outside knob/lever unlocked by key outside, thumbturn or closing door. Rotating inside knob/lever simultaneously retracts latchbolt and unlocks outside knob/lever. Auxiliary latch deadlocks latchbolt when door is locked. Inside knob/lever is always free for immediate egress.

Mechanical Option Description: Interior Indicator LOCK/UNLOCKED

Pocket Dimensions: 6-5/8" x 4-1/2"

Projection: 2.668"

Restrictions: None

Rose Escutcheon Design: B - Rose

Rose Escutcheon Dimensions: 2-9/16"

Screws: Combination

Series: L9000 Series Mortise Lock

Strike Height: 4-7/8 In.

Strike Number: 10-072

Strike Type: ASA

Strike Width: 1-1/4 In.

Subtype: Mortise Lock

Type: Locks, Cylinders, Cores, Keyblanks
