Attributes

Manufacturer surcharge: 3.5%

Accessible: Yes

Ada Compliance: Yes

Ansi: ANSI A156.2 Series 4000, Grade 1

Ansi Function: F86 - Storeroom

Baa Qualified: Yes

Backset: 2-3/4" Backset

Bolt Projection: 1/2 In.

Bore Hole Diameter: 2-1/8 In.

Box Depth Fraction: 9-1/2 In.

Box Height Fraction: 4-3/4 In.

Box Width Fraction: 8-1/4 In.

Commercial Residential: Commercial

Country of Origin: Mexico

Country of origin: Mexico

Cylinder Type: Schlage FSIC Prep with Core

Cylinders Present: Single Cylinder

Design: Rhodes

Door Thickness: 1-5/8 In. to 2-1/8 In.

Finish: Bright Chrome

Finish Description: Bright Chrome

Finish Family: Polished Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 80-Storeroom Lock

Function Family: Storeroom

Grade: Grade 1

Handing: Non-handed

Installation: Commercial

Keys: Cut

Latch Bore Diameter: 1 In.

Lever Knob: Lever

Lever Knob Design Name: Rhodes

Leverknob Design: RHO - Rhodes Lever

Leverknob Design Family: Straight Return Lever

Limited Warranty: 10 Years

Lock Face Size: 1-1/8 In. x 2-1/4 In.

Manufacturer Function: Storeroom Lock

Maximum Door Thickness: 2-1/8 In.

Minimum Door Thickness: 1-5/8 In.

Of Keys: 2

Origin: Mexico

Pack Height: 4.75"

Pack Height 2: 10"

Pack Length: 9.5"

Pack Length 2: 16.38"

Pack Qty: 1

Pack Volume: 372.28 in³

Pack Volume 2: 2394.84 in³

Pack Width: 8.25"

Pack Width 2: 14.63"

Pbs Options: '4540296,4541421

Pins: 6

Product Height: 3.44"

Product Length: 6.28"

Product Width: 2.94"

Projection: 2-15/16 In.

Rose Escutcheon: Rose

Roseescutcheon Design: 3-7/16" Rose Diameter

Roseescutcheon Dimensions: 3-7/16"

Screws: Wood/Machine Screws

Series: ND Series

Ship Weight: 5 lbs.

Std Latch Backset Dim: 2-3/4 In.

Std Latch Number: 13-247

Std Latch Type: Deadlatch

Std Strike Height: 4-7/8 In.

Std Strike Number: 10-025

Std Strike Type: ANSI Strike

Std Strike Width: 1-1/4 In.

Strike: ASA Strike

Strike Dimensions: 1-1/4 In. x 4-7/8 In.

Subtype: Cylindrical

Type: Mechanical Commercial Locksets

Ul Listing: UL/cUL Listed

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 6
