Jackson 311295S3628 Narrow Stile Rim Exit Device is engineered for seamless integration with narrow stile aluminum, hollow metal, or wood doors, making it a versatile choice for various applications. This exit device is specifically designed for standard 36" openings but can be trimmed to fit narrower door conditions, providing flexibility on-site. The device features a soft-touch push-pad that ensures smooth operation during emergencies, enhancing safety and accessibility. With standard hex key dogging, securing the device is simple and reliable. The surface-mounted roller strike enhances durability, while the robust construction includes extruded aluminum for the base and push-pad, complemented by stainless and hardened plated steel mechanical components. This non-handed exit device is ANSI/BHMA 156.3 certified, ensuring it meets industry standards for quality and safety. It accommodates doors with a thickness of 1-3/4" and includes necessary mounting hardware for straightforward installation. Available in a sleek satin aluminum finish, the Jackson 311295S3628 not only provides functionality but also adds a modern touch to any entrance. Explore the convenience and reliability of the Jackson 311295S3628, perfect for building professionals and knowledgeable homeowners seeking effective exit solutions for their properties.

Narrow Stile Rim Exit Device, with Low Profile Strike, Push-Pad Type, 36in, 628 Satin Aluminum - CRL / CR Laurence

The sleek, contemporary Jackson 1295 series rim panic exit device is designed for use with narrow stile aluminum, hollow metal or wood single doors, or paired doors when used with the 896 removable mullion. Sized for 36" standard openings, but may be trimmed for narrower conditions.

Features:

• Designed for use with 1-3/4" (44 mm) narrow, medium, and wide stile aluminum, wood or hollow metal doors
• Soft-touch smooth action push-pad
• Can be cut to size
• Standard hex key dogging
• Stocked in both 36" and 48" (914 mm and 1.22 m) widths
• Surface mounted roller strike standard
• Requires rim cylinder for keyed entry
• Base and Push-Pad: Extruded aluminum
• Mechanical Components: Stainless and hardened, plated steel
• Latch and Strikes: Sintered steel
• Metal end caps

Specifications:

• Certification: ANSI/BHMA 156.3
• Door Thickness: 1-3/4 in. (44.5 mm)
• Door Width: 36 in. (914.4 mm)
• Handing: Non handed
• Includes: Mounting hardware
• Material - End Cap: Aluminum
• Material - Housing: Aluminum
• Material - Latch & Strike: Sintered steel
• Material - Mechanical Components: Stainless and hardened plated steel
• Minimum Stile Width: 1-3/4 in. (44.5 mm)
• Model: 1295
• Panic Bar Base Height: 3-3/16 in. (81 mm)
• Panic Bar Projection: 2-7/8 in. (73 mm)
• Panic Bar Width Net: 34-1/2 in. (876.3 mm)
• Panic Dogging: Standard hex key dogging
• Panic Type: Rim
• Push Pad Width: 24 in. (609.6 mm)

Finishes:

• 628 - Satin aluminum
• 313 - Dark bronze
