Richelieu WEBSO1248509 1532 Series Heavy-Duty Pocket Door InstructionsRichelieu WEBSO1248509 1532 Series - Heavy Duty Pocket Door offers an exceptional design that redefines pocket door functionality. Engineered for seamless performance, this system utilizes a cassette that glides smoothly along a precision track, ensuring refined movement for doors weighing up to 100 lbs. Installation is straightforward, eliminating the need for a carrier strip and simplifying product selection with just two parameters: door height and thickness. This innovative pocket door system accommodates doors with a maximum height of 118 inches and a width of 39 inches, with a thickness ranging from 1.25 inches. A unique cable system effectively neutralizes "racking" during operation, while specially designed hinges allow for a soft and silent close, enhancing the user experience. Ideal for various applications, including hospitality, RVs, and micro-living, the Richelieu 1532 Series is the perfect solution for creating hideaway compartments. With a focus on both functionality and aesthetics, this heavy-duty pocket door system is a must-have for building professionals and discerning homeowners alike. The packaging format is per unit, and it ships via UPS, ensuring convenience and reliability for your projects.
1532 Series - Heavy Duty Pocket Door
The Accuride 1532 Pocket Door System is unrivaled in its design. Engineered for all-around excellence, this system uses a cassette that glides along a precision track to give your pocket door the most refined movement possible. The 1532 is easy to install with no carrier strip. Product selection is also made simple with only two essential parameters: door height and thickness.
- Max Door Weight: 100 lbs
- Max Door Height: 118 in
- Max Door Width: 39 in
- Max Door Thickness: 1.25 in
A novel cable system neutralizes "racking" when opening pocket doors, while special hinges bring those doors to a soft and silent close. The 1532 is the perfect movement solution for hideaway compartments in practically every industry, including hospitality, RVs, micro-living, and more!
IMPORTANT: 1 Set per door
Attributes
Application: Pocket Door
Brand: Accuride
Door Position: Inset/Inlay
Door Thickness: 13/16 to 1 1/4 in*
Door Weight: 99.2 lb*
Height: 15 3/4 to 23 5/8 in*
Load Capacity: 100 lb
Max Door Width: 39 3/8 in*
Max. Door Height: 118 in
Max. Door Width: 39 in
Packaging format: Per unit
Product #: AL1532-40P1-TI
Production Time: Special Online Order
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
