ABH A5505095 A5505 Stainless Steel Pin Barrel Hinge, Full Concealed, 12 Gauge, 1/8" Inset, Satin SSThe ABH A5505 Stainless Steel Pin Barrel Hinge is engineered for superior performance and durability, making it an ideal choice for demanding commercial applications. Crafted from 12-gauge 304 stainless steel, this full concealed hinge boasts a robust load capacity of 900 lbs, ensuring it can support heavy doors with ease.
Designed with a 1/8" inset and double edge guards on both faces, the A5505 enhances the aesthetics of your installations while providing added protection against wear and tear. The satin stainless steel finish (US32D) not only offers a sleek, modern look but also resists corrosion and tarnishing, making it suitable for a variety of environments.
This hinge is UL Listed for Fire Door Assemblies, providing a fire rating of up to 3 hours for hollow metal doors, ensuring compliance with safety regulations. With standard lengths available from 78¾" to 118¾", the A5505 is versatile enough to accommodate various door sizes up to a maximum width of 48".
The ABH A5505 is the perfect solution for architects, contractors, and facility managers seeking a reliable, heavy-duty hinge that meets stringent performance standards while maintaining a polished appearance.
Full concealed 12 gauge 304 stainless steel continuous hinge with 900 lb load capacity providing heavy duty performance for demanding applications.
A5505095: 12 Gauge, 1/8" Inset, Double Edge Guard
Key Features
- Full Concealed
- 12 Gauge 304 Stainless Steel
- Heavy Duty
- Door Edge Guards On Both Faces Of The Door
Specifications
| Model | A5505095 |
|---|
| Finish | Satin Stainless Steel |
|---|
| Finish Code | US32D |
|---|
| Length (in) | 95 |
|---|
| Family | A5505 |
|---|
| Material | 12 gauge 304 stainless steel |
|---|
| Finishes | US32, US32D, Custom Finishes Available |
|---|
| Standard Lengths | 78¾", 83⅛", 85", 95", 118¾" |
|---|
| Door Inset | 1/8" inset |
|---|
| Load Capacity | 900 lbs. door weight maximum |
|---|
| Door Width | 48" maximum |
|---|
| Fasteners | 12-24 x 1/2" undercut machine screws, stainless steel |
|---|
| Fire Rating | UL Listed for Fire Door Assemblies - 20 min (wood), 90 min (composite/hollow metal), 3 hr (hollow metal) |
|---|
Features
- Full Concealed
- Heavy Duty
- 12 Gauge 304 Stainless Steel
- Door Edge Guards On Both Faces Of The Door
Attributes
Ship via: No UPS - Common Carrier Only
BRAND_ NAME: ABH
Door Inset: 1/8" inset
Door Width: 48" maximum
Family: A5505
Fasteners: 12-24 x 1/2" undercut machine screws, stainless steel
Finish: Satin Stainless Steel
Finish Code: US32D
Finishes: US32, US32D, Custom Finishes Available
Fire Rating: UL Listed for Fire Door Assemblies - 20 min (wood), 90 min (composite/hollow metal), 3 hr (hollow metal)
Length (in): 95
Load Capacity: 900 lbs. door weight maximum
Material: 12 gauge 304 stainless steel
Model: A5505095
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard Lengths: 78¾", 83⅛", 85", 95", 118¾"
