ABH A5515085 Full Mortise Stainless Steel Continuous Hinge - 12 Gauge HD, Flush Mount, Bright Stainless SteelThe ABH A5515085 Full Mortise Stainless Steel Continuous Hinge is engineered for superior performance in demanding environments, featuring a robust 12 gauge construction that ensures exceptional strength and durability. Designed for flush mounting with no inset, this hinge provides a seamless aesthetic and is ideal for high-traffic applications, accommodating doors weighing up to 900 lbs. Its full concealed design not only enhances visual appeal but also protects against wear and tear over time.
Constructed from premium 304 stainless steel, the A5515085 is built to withstand harsh conditions, making it a reliable choice for commercial and institutional settings. The hinge is finished in bright stainless steel (US32), offering both elegance and resilience against corrosion.
Moreover, this continuous hinge includes a door edge guard on the stop side only, providing additional protection against impacts and ensuring longevity in heavy-use scenarios. It is UL listed for fire door assemblies, with ratings of up to 3 hours for hollow metal doors, ensuring compliance with stringent safety standards.
Choose the ABH A5515085 for a high-performing continuous hinge that combines functionality with sophisticated design, making it an essential component for modern architectural projects.
Full concealed 12 gauge 304 stainless steel continuous hinge with 900 lb load capacity providing extra heavy duty performance for demanding applications.
A5515085: 12 Gauge, No Inset, Flush Mount, Door Edge Guard, (Stop Side Only)
Key Features
- Full Concealed
- Extra Heavy Duty
- 12 Gauge 304 Stainless Steel
- Edge Guard Stop Side Only
Specifications
| Model | A5515085 |
|---|
| Finish | Bright Stainless Steel |
|---|
| Finish Code | US32 |
|---|
| Length (in) | 85 |
|---|
| Family | A5515 |
|---|
| Material | 12 gauge 304 stainless steel |
|---|
| Finishes | US32, US32D, Custom Finishes Available |
|---|
| Standard Lengths | 78¾", 83⅛", 85", 95", 118¾" |
|---|
| Door Inset | No inset, flush mount |
|---|
| Load Capacity | 900 lbs. door weight maximum |
|---|
| Door Width | 48" maximum |
|---|
| Fasteners | 12-24 x 1/2" undercut machine screws, stainless steel |
|---|
| Fire Rating | UL Listed for Fire Door Assemblies - 20 min (wood), 90 min (composite/hollow metal), 3 hr (hollow metal) |
|---|
Features
- Extra Heavy Duty
- Full Concealed
- Edge Guard Stop Side Only
- 12 Gauge 304 Stainless Steel
Attributes
BRAND_ NAME: ABH
Door Inset: No inset, flush mount
Door Width: 48" maximum
Family: A5515
Fasteners: 12-24 x 1/2" undercut machine screws, stainless steel
Finish: Bright Stainless Steel
Finish Code: US32
Finishes: US32, US32D, Custom Finishes Available
Fire Rating: UL Listed for Fire Door Assemblies - 20 min (wood), 90 min (composite/hollow metal), 3 hr (hollow metal)
Length (in): 85
Load Capacity: 900 lbs. door weight maximum
Material: 12 gauge 304 stainless steel
Model: A5515085
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard Lengths: 78¾", 83⅛", 85", 95", 118¾"
