ABH A5515WT083 Full Mortise Stainless Steel Continuous Hinge - 12 Gauge, Wide Throw, Bright Stainless Steel

The ABH A5515WT083 Full Mortise Stainless Steel Continuous Hinge is engineered for superior performance in high-traffic environments. Constructed from 12 gauge 304 stainless steel, this extra heavy-duty hinge supports a remarkable load capacity of 900 lbs, making it ideal for oversized or heavy doors in commercial settings. Its full concealed design ensures a sleek appearance while providing maximum durability and functionality.

This hinge features a wide throw and is designed for no inset, allowing for a flush mount application. The door edge guard on the stop side enhances protection, ensuring longevity even in demanding use cases. With a finish of bright stainless steel (US32), it not only offers corrosion resistance but also maintains a professional aesthetic suitable for various architectural styles.

Compliance is paramount; this hinge is UL Listed for Fire Door Assemblies, providing a fire rating of 20 minutes for wood doors, 90 minutes for composite or hollow metal doors, and up to 3 hours for hollow metal doors. The ABH A5515WT083 is available in standard lengths and custom finishes, making it a versatile choice for architects, contractors, and facility managers seeking reliability and performance in door hardware.

Full concealed 12 gauge 304 stainless steel continuous hinge with 900 lb load capacity providing extra heavy duty performance for the most demanding applications.

A5515WT083: 12 Gauge, Wide Throw, Custom, No Inset, Flush Mount, Door Edge Guard, (Stop Side Only)

Key Features

• Full Concealed
• 12 Gauge 304 Stainless Steel
• Extra Heavy Duty
• Edge Guard Stop Side

Specifications

Features

• Extra Heavy Duty
• Full Concealed
• Edge Guard Stop Side
• 12 Gauge 304 Stainless Steel
