ABH AB2204-48 Straight Pull, Stainless Steel, Round Ends, 48"-1", Satin BrassThe ABH AB2204-48 Straight Pull is a premier choice for architects, contractors, and facility managers seeking a blend of functionality and aesthetic appeal. Crafted from high-quality stainless steel, this pull features a sleek Satin Brass finish (US4) that complements a wide range of architectural styles. The round end construction not only enhances its visual appeal but also provides a smooth grip for effortless operation.
Available in variable diameter options of 1" and 1¼", the AB2204-48 measures 48 inches in length, making it suitable for various door types, including ½" glass, 1¾" wood or metal, and 2¼" wood or metal. The pull is designed for durability, ensuring long-term performance in high-traffic environments. It is compliant with industry standards, offering peace of mind for any commercial application.
With multiple mounting options-back-to-back (BTB) or single side (S)-and a range of custom finishes available, the AB2204-48 is adaptable to meet specific project needs. Whether used in corporate offices, educational facilities, or retail spaces, this straight pull delivers both style and strength, making it an essential addition to any commercial door hardware collection.
Straight Pull, Stainless Steel, Round Ends, Variable Diameter Options, 48"-1", Satin Brass
Straight stainless steel pulls with round end construction available in 1" and 1¼" diameters providing smooth operational feel.
AB2204-48: AB2204-48 - 48"-1"
Key Features
- Round End Construction
- Variable Diameter Options
- Smooth Operational Feel
Specifications
| Model | AB2204-48 |
|---|
| Finish | Satin Brass |
|---|
| Finish Code | US4 |
|---|
| Length (in) | 48 |
|---|
| Family | AB2204 / AB2214 |
|---|
| Material | Stainless steel |
|---|
| Finishes | US3, US4, US9, US10, US10B, US32, US32D, Custom Finishes Available |
|---|
| AB2204 | 1" Diameter, 2-3/4" Projection, 1-3/4" Clearance |
|---|
| AB2214 | 1-1/4" Diameter, 3" Projection, 1-3/4" Clearance |
|---|
| Length Options | 12", 24", 36", 48", 60", 72", 84", 96" (Custom available) |
|---|
| Mid Post | Standard for lengths over 72" |
|---|
| Mounting Options | BTB (Back-to-Back), S (Single Side Mounting) |
|---|
| Door Options | 1/2" (Glass), 1-3/4" (Wood or Metal), 2-1/4" (Wood or Metal) |
|---|
| C to C Options | 6" - 90" |
|---|
Custom door thickness available. Round ends provide smooth grip transition.
Features
- Round End Construction
- Smooth Operational Feel
- Variable Diameter Options
Attributes
AB2204: 1" Diameter, 2¾" Projection, 1¾" Clearance
AB2214: 1¼" Diameter, 3" Projection, 1¾" Clearance
BRAND_ NAME: ABH
C to C Options: 6" - 90"
Door Options: ½" (Glass), 1¾" (Wood or Metal), 2¼" (Wood or Metal)
Family: AB2204 / AB2214
Finish: Satin Brass
Finish Code: US4
Finishes: US3, US4, US9, US10, US10B, US32, US32D, Custom Finishes Available
Length (in): 48
Length Options: 12", 24", 36", 48", 60", 72", 84", 96" (Custom available)
Material: Stainless steel
Mid Post: Standard for lengths over 72"
Model: AB2204-48
Mounting Options: BTB (Back-to-Back), S (Single Side Mounting)
