ABH L0147-LH 3/4" Offset Pivot Set - Heavy Duty, Left Hand, Lead Lined, Bright Stainless SteelThe ABH L0147-LH 3/4" Offset Pivot Set is designed for heavy-duty applications, specifically engineered to support lead-lined doors weighing up to 800 pounds. This pivot set is an ideal choice for environments requiring radiation shielding, such as medical facilities and laboratories. The set includes a top pivot (L0180) and a bottom pivot (L0147B), ensuring seamless operation and robust performance.
Constructed from high-quality stainless steel, this pivot set features a bright stainless steel finish (US32) that not only enhances durability but also provides a sleek, modern appearance. The left-hand configuration accommodates a variety of door widths up to 48 inches and door thicknesses of 1-3/4 inches, making it versatile for various installation needs.
In addition to its impressive load capacity, the L0147-LH is UL Listed for use on 3-hour fire door assemblies, ensuring compliance with stringent safety standards. This pivot set is built for longevity and performance, making it an essential component for architects, contractors, and facility managers seeking reliable door hardware solutions.
For additional support, an intermediate pivot (L019) is required for door heights exceeding 60 inches. Choose the ABH L0147-LH pivot set for a combination of strength, safety, and style in your project.
3/4" Offset Pivot Set - Heavy Duty - Lead Lined, Pivot Set (Includes L0180 Top and L0147B Bottom), 3/4" Offset, Up to 800 lbs., Left Hand, Bright Stainless Steel
Heavy duty lead lined pivot set with 3/4" offset supporting doors up to 800 pounds and 48" width for radiation shielding applications.
L0147-LH: Pivot Set (Includes L0180 Top & L0147B Bottom), 3/4" Offset, Up to 800 lbs., Left Hand
Key Features
- Lead Lined Construction
- Heavy Duty Design
Specifications
| Model | L0147-LH |
|---|
| Finish | Bright Stainless Steel |
|---|
| Finish Code | US32 |
|---|
| Handing | Left Hand |
|---|
| Family | L0147-RH / L0147-LH |
|---|
| Material | Stainless steel |
|---|
| Finishes | US3, US4, US9, US10, US10B, US32, US32D, S1/ALPC, S2/BSPC, S3/BZPC, S4/BSPC, S5/DBPC, S8/WSPC, Custom Finishes Available |
|---|
| Load Capacity | 800 lbs. maximum door load |
|---|
| Door Width | 48" maximum |
|---|
| Door Thickness | 1-3/4" lead lined doors |
|---|
| Weight | 5 lbs. average per set |
|---|
| Fire Rating | UL Listed for Use on 3-Hour Fire Door Assemblies |
|---|
| Door Height | 60" to 90" (one intermediate pivot), additional pivot per 30" height |
|---|
| Components Included | L0180 Top Pivot, L0147B Bottom Pivot |
|---|
Handed - specify LH or RH.
L019 lead lined intermediate pivot required (order separately).
Features
- Lead Lined Construction
- Heavy Duty Design
Attributes
BRAND_ NAME: ABH
Components Included: L0180 Top Pivot, L0147B Bottom Pivot
Door Height: 60" to 90" (one intermediate pivot), additional pivot per 30" height
Door Thickness: 1-3/4" lead lined doors
Door Width: 48" maximum
Family: L0147-RH / L0147-LH
Finish: Bright Stainless Steel
Finish Code: US32
Finishes: US3, US4, US9, US10, US10B, US32, US32D, S1/ALPC, S2/BSPC, S3/BZPC, S4/BSPC, S5/DBPC, S8/WSPC, Custom Finishes Available
Fire Rating: UL Listed for Use on 3-Hour Fire Door Assemblies
Handing: Left Hand
Load Capacity: 800 lbs. maximum door load
Material: Stainless steel
Model: L0147-LH
Weight: 5 lbs. average per set
