Adams Rite 2190-312-301-04 Dual Force 2190 Interconnected System

Adams Rite 2190-312-301-04 Dual Force 2190 Interconnected Lock offers a robust solution for access control and security on aluminum stile doors. With a backset of 1-1/8 inches, this lock features a flat strike and a dark bronze faceplate complemented by a sleek satin brass low-profile curve lever trim. Designed for out-swinging doors, the Dual Force 2190 integrates both a latch and a deadbolt, enabling quick and panic-proof exits. The key mechanism allows for the simultaneous retraction of both the latch and deadbolt from the inside, while the exterior lever retracts the latch only. This unique interconnect feature enhances security without sacrificing convenience. A latch holdback option is available, allowing easy management of door access. Constructed with a 5/8-inch throw latchbolt made of solid brass and a stainless steel deadbolt with a 1-inch throw, this lock is built to last. Its auxiliary deadlatch pin prevents unauthorized entry methods, ensuring peace of mind. The 2190 lock is compatible with a standard mortise cylinder, and customization options include various lever styles and finishes. This lock not only meets commercial standards but also adapts seamlessly to different door constructions, making it a versatile choice for any project.

Dual Force 2190 Interconnected

Dual Force Interconnected Lock, 1-1/8" Backset, Flat Strike, Dark Bronze Faceplate, Low Profile 01 Curve Lever Trim, Satin Brass

The Dual Force 2190 Interconnected Deadbolt/Deadlatch provides access control and security for aluminum stile doors. Latch and deadbolt capabilities are combined for fast, easy, and panic-proof exiting. The Dual Force 2190 combines the access control capabilities of a latch with the security of a deadbolt. The key retracts and extends the deadbolt (and deadlatch) from either side. The exterior lever retracts the latch only, while the inside lever retracts the deadbolt and latch simultaneously for fast, easy, panic-proof exiting. Intended for out-swinging doors. Key or thumbturn retracts or extends deadbolt or deadlatch. Inside lever retracts both when configured with interconnect feature. Outside lever retracts latch only. Latch holdback feature activated or deactivated by turning key to retract latch and sliding holdback button on faceplate down to hold and up to release. 2190 will not work without its specially designed strike - included standard in package.

Interconnected Deadbolt/Deadlatch provides access control and security for aluminum stile doors.

• Cylinder Backset: 1-1/8” or 1-1/2” only.
• Latchbolt/Deadbolt: Latchbolt: 5/8” throw, solid brass. Easily reversible using only a screwdriver. Deadbolt: 1” throw, stainless steel.
• Auxiliary Deadlatch Pin: Stainless steel. Deadlocks latch bolt to prevent “loiding” or case-knife entry.
• Faceplates: Measures 1” x 6-7/8”. Include FaceStyle faceplate system that adapts to flat, radius, or beveled door edge. Radius with weatherseal faceplate available separately.
• Strikes: Standard strike furnished is the 2101-01 for flat jamb where door closes flush or nearly flush. The 2101 covers MS® Deadlock strike preparation with modification, and the 4901 Deadlatch strike directly. Also available in radius version for opposite stile pairs of doors and with extended lip strikes for special jamb conditions.
• Cylinder Cam: Operable by any standard mortise cylinder with MS® cam, dimensioned as shown. Cylinders with MS® cams can be readily obtained from most cylinder manufacturers. See CYLINDERS section for cylinder make, thumbturn and trim ring information.
• Options: Specify trim option, lever style, finish, and strike.  Also adapts to paddle operator 4591. See 2290 for wood or steel door version for stile and rail type door construction. Note that the low profile trim (trim option 3) is recommended for in-swing door applications. Please refer to 3080 (TRIM) for full offering of designer handle sets.
