Alarm Lock AL-IME2-PIE Electrical Accessories

Your Price: $208.34

Retail Price:$406.51

Your Savings:$198.17(49%)

Plug-In Wireless Expander, Version 2 Gateways

Part Number : ALL_ALIME2PIE

Availability: 42 In Stock

Quantity

Alarm Lock AL-IME2-PIE Electrical Accessories

Plug-In Wireless Expander, Version 2 Gateways

NETWORK RANGE:
Gateway/Expander to Locks: Clear field range 500'. Typical indoor range, Networx 75-175'; ArchiTech Networx 50-125'. Note: Actual range varies with building construction.
Gateway/Expander to Expander: Clear field range 500'. Typical indoor range, 75- 175'. Note: Actual range varies with building construction.
AL RADIO LINK:
900 MHz GFSK
50 Channels
10 mW power output
POWER:
Peak Supply Current: 650 mA
Input Voltage: 5 - 6 volts AC
Occupies one(1) 12VAC Outlet as External Power
ENVIRONMENTAL
Operating Temperature: -20° to 60°C (-4° to 140°F)
Storage Temperature: -40° to 85°C (-40° to 185°F)
PHYSICAL CHARACTERISTICS
Enclosure Size 4.5"H x 6.0"W x 1.94"D, 0.5lbs.

Features

10 mW power output
Network Interface:
Power:
AL Radio Link:
Input Voltage: 5 - 6 volts AC
Software Supported:
Physical Characteristics:
Network Range:
900 MHz GFSK
Storage Temperature: -40° to 85°C (-40° to 185°F)
Enclosure Size 4.5"H x 6.0"W x 1.94"D, 0.5lbs.
Peak Supply Current: 650 mA
Environmental:
Trilogy Networx supported by Alarm Lock DL-WINDOWS for centralized programming, database management and updates; free download available online. Optional Enterprise Real-Time Processing Solution choice of Lenel OnGuard® or Continental CardAccess® Integration.
Operating Temperature: -20° to 60°C (-4° to 140°F)
Protocols: TCP/IP, UDP/IP, DHCP
Gateway/Expander to Expander: Clear field range 500'. Typical indoor range, 75- 175'. Note: Actual range varies with building construction.
Interface: Ethernet, 10Base-T or 100Base-TX (using RJ45 Jack)
Gateway/Expander to Locks: Clear field range 500'. Typical indoor range, Networx 75-175'; ArchiTech Networx 50-125'. Note: Actual range varies with building construction.
50 Channels

Access Type: Expander Module

Alternate Codes: AL-IME2-PIE, ALIME2PIE

Audit Trail: 40000 Events

Category: Access Control, Access Management, Wireless

Code Length: 3-6

Communication Frequency: 2.4 GHz, 900 mHz

Communication Range: Up To 200' Indoor, Up to 900' Clear Line Of Sight

Communication Technology: 802.11B/G, Bluetooth Low Energy, Ethernet

Compatibility: Trilogy Networx Locksets

Credential Technology: HID iClass, HID Proximity

Door Application: Access Control

Encryption Technology: 128-bit AES, RF-Link

Finish: White

Finish Color: White

Input Voltage: 5-6V

Manufacturer: Alarm Lock Systems Inc

Mounting: Ceiling, Wall

Pack Qty: 1

Power Supply Type: External

Series: Alarm Lock Parts and Accessories

Subtype: Electrical Accessories

Type: ACCESS CONTROL

Unit of Measure: Each

Users: 5000 User Codes

Voltage Type: VAC - Alternating, VDC - Direct
