Alarm Lock DL5300/26D Trilogy Digital Mortise Lock Satin Chrome Finish

• Door Thickness: Fits 1-5/8" to 1-7/8". Other thickness, please consult factory
• Backset: 2-3/4" (2-3/8" also available)
• Strike: 1-1/8" x 2-3/4" T strike & 1-1/4" x 4-7/8" ASA strike included
• Latchbolt: UL Listed, fire rated 3 hours, 1/2" throw reversible
• Handing: Non-handed
• Power: 5 AA alkaline batteries (included)
• Keypad: All metal, 12 button. All functions programmed through keypad on both sides
• Door prep: Standard ANSI A115 Series prep, modified by adding additional through-bolt holes
• Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed 10C Positive Pressure Specification. FCC Certified. ADA compliant levers
• Cylinder: 6 pin solid brass, SC1 keyway, furnished with all key override locks. Schlage, Corbin-Russwin CL, Sargent 480 series, ASSA 65-611 & Lori cylinders can also be used with HW620 tailpiece (supplied)
• Interchangeable Core Models: Standard model accepts 6 & 7 pin cylinders from Best, Falcon, and Arrow.
• Retrofits Most Cylindrical Locksets and Digital Locks
• Multi-Level User Codes and One-Time Service Codes
• 100,000 Cycles Typical Battery Life
• Vandalproof All-Metal Keypad
• Non-Handed

Features

• Latchbolt: UL Listed, fire rated 3 hours, 1/2" throw reversible
• Strike: 1-1/8" x 2-3/4" T Strike & 1-1/4" x 4-7/8" ASA Strike included
• Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed 10C Positive Pressure Specification. FCC Certified. ADA compliant levers
• Keypad: All metal, 12 button. All functions programmed through Keypad on both sides
• Note: Key override operates latch on primary side only. Key override on secondary side protects battery pack.
• Interchangeable Core Models: Standard Model accepts 6 & 7 pin cylinders from Best, Falcon, and Arrow.
• Handing: Non-handed
• Door Prep: Standard ANSI A115 Series Prep, modified by adding additional through-bolt holes
• Door Thickness: Fits 1-5/8" to 1-7/8". Other Thickness, please consult factory
• Cylinder: 6 pin solid brass, SC1 keyway, furnished with all key override locks. Schlage, Corbin-Russwin CL, Sargent 480 Series, ASSA 65-611 & Lori cylinders can also be used with HW620 tailpiece (supplied)
• All DL5300 Locks are Weather Resistant
• Power: 5 AA alkaline batteries (included)
• Backset: 2-3/4" (2-3/8" also available)
