Arrow Lock D64 26D CS Grade 1 Classroom Deadbolt

Arrow D64 26D CS Grade 1 Classroom Deadbolt offers exceptional security and reliability for various environments, including industrial, institutional, and commercial applications. This heavy-duty deadbolt meets Grade 1 standards, ensuring it can withstand extreme conditions while providing peace of mind. Designed with a robust two-piece housing, the deadbolt features a free-spinning outer ring that prevents wrenching, enhancing overall security. The solid steel deadbolt boasts a 1" throw and includes a hardened, free-spinning steel pin for added protection. With options for backsets of 2-3/8" and 2-3/4", this deadbolt is versatile enough to fit a range of door thicknesses from 1-3/8" to 1-3/4". The Arrow D64 is equipped with a Schlage C keyway and comes with two nickel silver keys, allowing for easy access control. It’s also adaptable, accepting both 6 and 7 pin small format interchangeable cores, and is reversible for convenient installation. Included with the deadbolt are standard wood frame and optional metal frame strikes, ensuring compatibility with various door setups. With a satin chrome finish and a standard lock face size of 2-1/4" x 1-1/8", the Arrow D64 combines durability with aesthetic appeal, making it an excellent choice for enhancing security in any facility.

Grade 1 Classroom Deadbolt

Deadbolt, Classroom, Schlage C Keyway, Satin Chrome

Arrow D Series deadlocks are engineered to perform under the most extreme conditions where security is critical. Our Grade 1 extra heavy duty deadlock surpasses the demands of industrial, institutional and commercial applications.

Arrow D Series deadlocks are engineered to perform underthe most extreme conditions where security is critical.

The Arrow D series is a Grade 1 extra heavy duty deadlock that suprasses the demands of industrial, institutional and commercial applications.

• Housing–Two-piece housing, with free-spinning outer ring to prevent wrenching. Concealed mounting screws are standard on double cylinder functions. Deadbolt–1" (25.40mm) throw, solid steel deadbolt with hardened, free spinning, steel pin & insert.
• Backset–2-3/8" (60.32mm), 2-3/4" (69.85mm).
• Deadbolt fronts–2-1/4" (57.15mm) x 1" (25.40mm) standard for 2-3/8" (60.32mm) backset, 2-1/4" (57.15mm) x 1-1/8" (28.57mm) standard for 2-3/4" (69.85mm) backset. Drive-in deadbolts are available.
• Doors–1-3/8" (34.925mm) to 1-3/4" (44.45mm) thick standard.
• Strikes–Supplied standard with the #346 wood frame strike and BX91D strike reinforcement. The #345 metal frame strike is optional.
• Handing–All functions are reversible.
• Cylinder, Standard–Solid brass, Arrow “A” keyway, 6 pin cylinder. Supplied with two nickel silver keys. Available in Schlage CS keyway and other competitive keyways.
• Cylinder Options–Accepts 6 or 7 pin, small format, interchangeable cores. Supplied less cores. Will accept Best ™ or Falcon™ type cores (except the E41).

Resources

• Arrow D Series Deadbolts Cut Sheet
• D Series Cut Sheet
• D Series Instructions - IC
• Management Control Deadbolt Cut Sheet
