Arrow Lock MLX01SR26D-2 3/4 BS Passage Sierra Lever, 626/US26D Satin Chrome

Arrow Lock Company MLX01SR26D-2 3/4 BS Passage Sierra Lever offers exceptional security and durability, making it an ideal choice for commercial applications. This robust Grade 2 lockset features a freewheeling lever, designed for abuse resistance, ensuring longevity and reliability even in high-traffic environments. The two-screw installation method simplifies the setup process, allowing for quick and efficient installation. This lockset meets ANSI/BHMA A156.2, Series 4000, Grade 2 standards and is Underwriters Laboratories (UL and CUL) listed for use on 3-hour, A-label single swinging doors. The MLX01SR26D-2 is also compliant with the ADA Accessibility Code, ensuring it meets modern accessibility requirements. Designed for standard door preparations, this lockset fits doors ranging from 1-3/8" to 1-3/4" thick and requires a 2-1/8" bore. The stainless steel latch features a 1/2" throw and is UL listed for added security. With a sleek satin chrome finish, this passage lever not only enhances security but also adds a touch of elegance to your doors. Backed by a 10-year mechanical warranty, the Arrow Lock Company MLX01SR26D-2 is a reliable choice for those looking to upgrade or replace their locking hardware.

Passage Sierra Lever, 626/US26D Satin Chrome

MLX Series is a robust Grade 2 lockset featuring a Freewheeling Lever for abuse resistance, two screw lockset install for quick installation and 10 Year Mechanical Warranty. The perfect solution for replacing or upgrading lockets in commercial applications.

Features:

• ANSI/BHMA A156.2, Series 4000, Grade 2.
• Underwriters Laboratories (UL and CUL) listed for use on 3 hour, A label single swinging doors.
• Federal Specification FF-H-106C.
• ANSI A117.1 Accessibility Code.
• California State Reference Code–for levers returning to within 1/2" (12.7mm) of door surface.
• ADA/Americans with Disabilities Act: Acceptable Door Hardware: Section 4.13.9.

Specifications:

• Door Preparation: Requires standard 2-1/8" (54mm) bore through door.
• Backset: 2-3/4" (70mm) standard. 2-3/8" (60mm) backset latch available separately.
• Door Thickness: Fits 1-3/8" (35mm) to 1-3/4" (44mm) doors standard.
• Latch: Stainless Steel 1/2" (13mm) throw, UL Listed, guarded latchbolt on all locking Functions.
• Latch Front: 1-1/8" x 2-1/4" x 2-3/4" (70mm) backset.
• Exposed Trim: MLX Levers are pressure cast zinc measuring 4-3/4" (121mm) in length. MLX Roses are wrought brass 3-11/32" (85mm) diameter. Total projection from face of door is 2-17/32" (65mm).
• Freewheeling Lever.
• Warranty: Ten Year Warranty.
• Handing: Non-handed.
• Strike: 4-7/8" ANSI (124mm).
• Cylinder: Standard: solid brass, 6-pin, keyed different, Arrow A or Schlage C keyway. Optional: prep for small or large format interchangeable core cylinder (cylinder not included).
• Keys: 2 brass keys.

Functions:

• MLX01: Passage: Latchbolt operated by lever either side.
• MLX72: Privacy: Latch operated by lever either side except when outside lever is locked by pushing inside button. Outside lever unlocked by turning inside lever, using emergency key, or closing door. Inside lever always operates latch.
• MLX08: 1/2 Dummy Trim: Rigid trim for one side of door only. Used as pull or to match active trim.
• MLX81: Entrance: Latchbolt operated by lever either side except when outside lever is locked by turn-button inside. When outside lever is locked, latchbolt operated by key outside or turning inside lever. Inside button must be manually released.
• MLX82: Storeroom: Outside lever always locked. Latchbolt operated by key in outside lever, or by turning inside lever.
• MLX87: Classroom: Latchbolt operated by lever either side except when key outside locks outside lever. Inside lever always free. Key outside locks/unlocks outside lever only.

Finishes:

• 605/US3 - Bright Brass
• 613E/US10BE - Dark Oxide Satin Bronze Equivalent
• 626/US26D - Satin Chromium Plated
