Attributes

Ansi: F84

Ansi Function: F84 - Classroom

Backset: 2-3/4" Backset

Base Material: Brass, Bronze

Bolt Projection: 1/2"

Bolt Protection: 1/2"

Bore Hole Diameter: 2-1/8"

Box Depth Fraction: 10"

Box Height Fraction: 4-1/2"

Box Width Fraction: 8"

Burglar Rated: No

Commercial Residential: Commercial

Country of Origin: Usa

Country of origin: United States

Cylinder Type: Less Cylinder

Cylinders Present: Single Cylinder

Design: Zinc Newport Lever and D Rose

Door Thickness: 1-3/4" - 2"

Finish: Satin Chrome

Finish Description: Satin Chrome

Finish Family: Matte Silver

Fire Rated: 3 Hours {A}

Fire Rating: 3 Hours {A}

Function: 55-Classroom

Function Family: Classroom

Grade: Grade 1

Hand: Not Handed

Handing: Non-handed

Installation: Commercial

Latch Backset Dim: 2-3/4"

Latch Bore Diameter: 1"

Latch Number: 780F82

Latch Type: Dead Latch (Guarded)

Lever Knob: Lever

Lever Knob Design: NZ - Newport

Lever Knob Design Name: Newport

Leverknob Design: NZ - Newport Lever

Leverknob Design Family: Straight Return Lever

Limited Warranty: 10 Year Warranty

Lock Face Size: 2-1/4" x 1-1/8"

Manufacturer Function: Classroom

Maximum Door Thickness: 2"

Minimum Door Thickness: 1-3/4"

Origin: United States

Pack Height: 4.5"

Pack Height 2: 10.5"

Pack Length: 10"

Pack Length 2: 15.5"

Pack Qty: 1

Pack Volume: 360 in³

Pack Volume 2: 2359.88 in³

Pack Width: 8"

Pack Width 2: 14.5"

Pins: 6

Product Height: 4.5"

Product Length: 10"

Product Width: 8"

Projection: 2-7/8"

Rose Escutcheon: Rose

Rose Escutcheon Design: D - Rose

Roseescutcheon Design: D Rose

Roseescutcheon Dimensions: 2-3/4"

Screws: Combination

Series: CL3100 Series

Ship Weight: 7 lbs.

Std Latch Backset Dim: 2-3/4"

Std Latch Number: 780F82

Std Latch Type: Deadlatch

Std Strike Height: 4-7/8"

Std Strike Number: SA114

Std Strike Type: ANSI Curved Lip Strike

Std Strike Width: 1-1/4"

Strike: ANSI Curved Lip Strike

Strike Dimensions: 1-1/4" x 4-7/8"

Strike Height: 4-7/8"

Strike Number: 217L13

Strike Type: ASA

Strike Width: 1-1/4"

Subtype: Cylindrical

Type: Mechanical Commercial Locksets

Ul Listing: ANSI A156.2, Series 4000, Grade 1, UL Listed

Unit of Measure: Each

Unit of Measure 2: Case

Unit of Measure 2 Qty: 6
