CRL 24SRPPS Polished Stainless 24" Right-Handed Back-to-Back "S" Ladder PullC.R. Laurence 24SRPPS Polished Stainless 24" Extra Length Right Handed "S" Ladder Style Back-to-Back Pull offers a modern and sleek solution for glass door hardware. Designed for use with doors made from 3/8" to 3/4" (10 to 19 mm) thick tempered glass, this pull features a robust 1-1/4" (32 mm) diameter heavy wall 304 alloy stainless steel tubing, ensuring durability and a polished aesthetic. Available in three sizes and two finishes-polished stainless and brushed stainless-this pull handle can be customized to meet specific architectural requirements. The back-to-back mounting design, secured with supplied through-bolts, provides stability and ease of installation. The handle is handed left and right, ensuring that the exposed set-screws are always positioned on the interior side of the door, enhancing visual appeal. For added convenience, custom sizes and finishes are offered, allowing you to tailor the pull to your project's specifications. Additionally, it requires two 5/8" (16 mm) diameter holes for glass fabrication. Remember, if installing pairs of doors, the opposite handed pull will be necessary. Experience elegance and functionality with the C.R. Laurence 24SRPPS "S" Style Ladder Pull Handle.
Polished Stainless 24" Extra Length Right Handed "S" Ladder Style Back-to-Back Pull
- Three Sizes in Two Popular Finishes for 3/8" to 3/4" (10 to 19 mm) Glass
- Designer Left and Right Hand Models Available
- 1-1/4" (32 mm) Diameter Heavy Wall 304 Alloy Stainless Steel Tubing
- Custom Finishes and Sizes Available
CRL "S" Style Ladder Pull Handles are for back-to-back mounting with supplied through-bolts. They are intended for use on doors made from 3/8" to 3/4" (10 to 19 mm) thick tempered glass. Stock sizes range from 24" to 48" (610 mm to 1.22 m) overall height. Standard finishes are polished stainless and brushed stainless. The Pulls are handed left and right to ensure the exposed set-screws are always on the interior side of the door. Handing is determined from the exterior side looking in.
Custom sizes and finishes are available to meet architectural specifications. For additional information or to begin the custom design process, contact our Technical Sales Department.
SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) Glass
Construction: 1-1/4" (32 mm) Diameter Stainless Steel Tubing
Glass Fabrication Required: Two 5/8" (16 mm) Diameter Holes
Product Warning:
This handle is "handed" and the opposite handed pull will be needed for pairs of doors. For single sided Ladder Pulls, please contact our Technical Sales Department.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Stainless Steel Advisory:
Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Attributes
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Diameter: 1-1/4 in. (32 mm)
Finish/ Color:: Polished Stainless Steel
Glazing Thickness: 3/8 in. To 3/4 in. (10 mm To 19 mm)
Material: Stainless Steel
Mounting Center To Center: 12 in. (305 mm)
Mounting Hole Diameter: 5/8 in. (16 mm)
Mounting Type: Back-To-Back
Overall Length: 24 in. (610 mm)
Shipping Limitations: None
