CRL 3D130F3R1BS Blumcraft Brushed Stainless Right Hand Reverse Rail Mount Deadbolt Handle
Images may not represent actual product and finish

CRL 3D130F3R1BS Blumcraft Brushed Stainless Right Hand Reverse Rail Mount Deadbolt Handle

Your Price: $8,519.99
Retail Price:$10,199.98
Your Savings:$1,679.99(16%)
The CRL Blumcraft Brushed Stainless Deadbolt Handle offers secure access and modern design for 3/4" tempered glass doors.
Part Number : CRL_3D130F3R1BS
Availability: 0 Special order - ships in 5-10 business days
CRL 3D130F3R1BS Blumcraft Brushed Stainless Right Hand Reverse Rail Mount Deadbolt Handle

C.R. Laurence 3D130F3R1BS Blumcraft Brushed Stainless Right Hand Reverse Rail Mount Cylinder/Thumbturn 'F' Deadbolt Exterior Handle is the ideal choice for enhancing both security and style in your 3/4" tempered glass doors. This robust handle is UL classified and ANSI/BHMA certified, ensuring that it meets the highest standards for safety and durability. Designed for easy installation on single or double doors, it fits 36" to 48" wide doors and heights from 90" to 102" without the need for modifications. The handle features a keyed lock on both the interior and exterior, with an optional thumbturn for added convenience. Its sleek brushed stainless steel finish not only provides a contemporary aesthetic but also ensures long-lasting performance. Custom sizes and finishes are available by special order, allowing you to tailor the handle to your specific needs. The 1-1/4" diameter construction of 304 stainless steel tubing enhances its strength while maintaining a refined look. Additionally, the DB130 series is compatible with electric strikes, expanding its versatility for various applications. Whether for commercial or upscale residential environments, this deadbolt handle seamlessly combines functionality with modern design.

Blumcraft Brushed Stainless Right Hand Reverse Rail Mount Cylinder/Thumbturn 'F' Deadbolt Exterior Handle for 3/4" Glass

  • For 3/4" (19 mm) Tempered Glass Doors
  • UL Classified
  • Easy Secure Access
  • ANSI/BHMA Certified
  • DB130 Series Can Be Used With an Electric Strike
  • Custom Sizes Ship Within One to Two Weeks
  • Available with a Wide Selection of Exterior Fixed Pull Handles on Special Order
  • Certification: ANSI/BHMA A156.16 Grade 1
  • Custom Finishes Available by Special Order
  • Custom Sizes Ship within One to Two Weeks

This CRL-Blumcraft® Glass Door Deadbolt Handle is designed to allow maximum view and a contemporary look to 3/4" (19 mm) tempered glass doors. Installations can be made on single or double doors. For your convenience, we have designed the handles so they are ready-to-install on 36" to 48" (914 mm to 1.22 m) wide doors ranging in height from 90" to 102" (2.29 to 2.59 m) high without modifications. Keyed Lock standard on interior and exterior side of handle. Optional thumbturn to replace keyed lock. Custom Headers available with your choice of pre-installed hardware. Dustproof Strike available for doors secured at bottom.


SPECIFICATIONS
Material:
  • 1-1/4" (32 mm) Diameter 385 Bronze or 304 Stainless Steel Tubing (2 mm Thick)
    Glass Thickness:
  • 3/4" (19 mm)
    Glass Fabrication: Varies
  • Please contact CRL Technical Sales

    ORDERING OPTIONS
    When ordering Deadbolt Handles you must specify:
  • Exterior Handle Option (
  • Right or Left Hand (as Viewed from the Outside)
  • Rail Mount (for Doors with Full Length Rails) or Glass Mount (for Doors with Patch Rails)
  • Single or Double Door Strike (for Single Acting Doors)
  • Brushed or Polished Stainless, Satin or Polished Brass Finish

    For more information contact CRL Commercial Products Technical Sales Department.

    Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

    Stainless Steel Advisory:
    Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.

    • Attributes

    Ship via: No UPS - Common Carrier Only

    Application: DRS Rail Mount

    Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov

    Diameter: 1-1/4 in. (32 mm)

    Finish/ Color:: Brushed Stainless Steel

    Glazing Thickness: 3/4 in. (19 mm)

    Handing: Right Hand Reverse

    Keying: Cylinder / Thumb Turn

    Latching: Top

    Material: Stainless Steel (Alloy 304)

    Maximum Door Height: 102 in. (2591 mm)

    Maximum Door Width: 48 in. (1219 mm)

    Shipping Limitations: No UPS - Common Carrier Only

    Top Latch Type: Deadbolt
