CRL 6901 690 Series Satin Anodized Wall/Ceiling Mount Sliding Door with Fixed Panel Kit is engineered for durability and aesthetic appeal, making it an excellent choice for both residential and commercial applications. Designed to accommodate 3/8" to 1/2" (10 to 12 mm) tempered glass, this kit can support sliding doors weighing up to 330 pounds (150 kg). The 118" (3 m) track length ensures a smooth and reliable operation, while the rollers allow for up to 1/4" (6 mm) of vertical adjustments to facilitate precise door alignment after installation. This versatile kit includes all necessary components, except for the tempered glass and pull hardware, making installation straightforward. It features a satin anodized finish, but options are available in brushed stainless anodized and matte black, with custom cladding or powder coating upon request. With a minimum sliding panel width of 30-7/8" (785 mm) for single-direction control and 42-1/2" (1080 mm) for dual-direction control, the CRL 690 Series is adaptable to various design requirements. Existing installations can be upgraded easily by ordering compatible kits, ensuring that functionality and style are always within reach. For assistance with selection or installation, CRL Technical Sales is ready to help.
690 Series Satin Anodized Wall/Ceiling Mount Sliding Door with Fixed Panel Kit
CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the "Softbrake" braking system. All come with everything you need except the tempered glass and pull hardware. Kits are available in satin anodized, brushed stainless anodized, and matte black finishes with a special order option to clad or powder paint in many architectural finishes. Contact CRL Technical Sales for Commercial Products for kit selection or installation assistance.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Ship via: No UPS - Common Carrier Only
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Satin Anodized
Glazing Thickness: 3/8 To 1/2 in. (10 To 12 mm)
Length: 118 in. (2997 mm)
Shipping Limitations: No UPS - Common Carrier Only
Track Length: 118 in. (2997 mm)
