CRL 6901BSA 690 Series Brushed Stainless Sliding Door Fixed Panel Mount Kit

Your Price: $1,881.49

Retail Price:$2,252.48

Your Savings:$370.99(16%)

Elevate your space with the CRL 6901BSA Sliding Door Kit, designed for heavy tempered glass and seamless installation.

Part Number : CRL_6901BSA

Availability: 46 In Stock

Quantity

Description

CRL 6901BSA 690 Series Brushed Stainless Sliding Door Fixed Panel Mount Kit

C.R. Laurence 6901BSA 690 Series Brushed Stainless Anodized Wall/Ceiling Mount Sliding Door with Fixed Panel Kit offers a flawless blend of functionality and modern aesthetics for your architectural needs. Designed to accommodate 3/8" to 1/2" (10 to 12 mm) tempered glass, this robust kit supports doors weighing up to 330 pounds (150 kg), making it ideal for both residential and commercial applications. The kit includes a generous 118" (3 m) track, allowing for smooth operation and easy installation. With vertical adjustment capabilities of up to 1/4" (6 mm) in the rollers, aligning doors after installation has never been simpler. The CRL 690 Series is available in various finishes, including satin anodized, brushed stainless anodized, and matte black, with customization options for architectural finishes upon request. This comprehensive kit comes complete with all necessary components, including top hangers, roller stops, end caps, door edge guards, and a bottom guide, ensuring you have everything you need to achieve a polished look. The minimum sliding panel width is 23-5/8" (600 mm), and existing installations can be easily upgraded with Softbrake kits for enhanced performance. For further assistance with kit selection or installation, reach out to CRL Technical Sales.

690 Series Brushed Stainless Anodized Wall/ Ceiling Mount Sliding Door with Fixed Panel Kit

Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
Track Length is 118" (3 m)
Use Monolithic Tempered Glass

CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the "Softbrake" braking system. All come with everything you need except the tempered glass and pull hardware. Kits are available in satin anodized, brushed stainless anodized, and matte black finishes with a special order option to clad or powder paint in many architectural finishes. Contact CRL Technical Sales for Commercial Products for kit selection or installation assistance.

Minimum sliding panel width of 23-5/8" (600 mm). Existing CRL690 Series installations can be easily upgraded to CRL695 Series by ordering CRL695SBK Softbrake kits, minimum door panel width 34-1/4" (870 mm).

Kit Contains:

118" (3m) of CRL4930EXT Track kit

1 Set CRL6939 Top Hangers

1 Set CRL6942 Roller Stops

1 Set CRL4937 End Caps

1 Set CRL2945 Door Edge Guards

1 Set CRL290TF Top Track Insert Fasteners

1 Each CRL Bottom Guide

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Attributes

Ship via: No UPS - Common Carrier Only

Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov

Finish/ Color:: Brushed Stainless Anodized

Glazing Thickness: 3/8 To 1/2 in. (10 To 12 mm)

Length: 118 in. (2997 mm)

Shipping Limitations: No UPS - Common Carrier Only

Track Length: 118 in. (3000 mm)
