CRL 690DMBL 690 Series Matte Black Sliding Door Kit for Drop Ceilings

C.R. Laurence 690DMBL 690 Series Matte Black Drop Ceiling Mount Sliding Door Kit delivers a seamless blend of style and functionality for modern spaces. Designed for use with 3/8" to 1/2" (10 to 12 mm) tempered glass, this kit can accommodate sliding doors weighing up to an impressive 330 pounds (150 kg), making it ideal for both residential and commercial applications. The 118" (3 m) track ensures smooth operation, while the rollers feature up to 1/4" (6 mm) of vertical adjustment, enabling precise door alignment after installation. This versatility enhances the user experience, allowing for easy adjustments to maintain a perfect fit. Included in the kit are essential components: one set of CRL6939 top hangers, CRL6942 roller stops, CRL4937 end caps, CRL2945 door edge guards, CRL290TF top track insert fasteners, and a CRL bottom guide. Available in a striking matte black finish, this door kit can also be customized with various architectural finishes upon special order. For additional flexibility, existing CRL690 Series installations can be upgraded to the CRL695 Series with compatible Softbrake kits. Elevate your design with the C.R. Laurence 690DMBL, where aesthetics meet durability and performance.

690 Series Matte Black Drop Ceiling Mount Sliding Door Kit

• Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
• Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
• Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
• Track Length is 118" (3 m)
• Use Monolithic Tempered Glass

Resources

• 690 695 Series Grid System Installation Instructions
• 690 695 Series Sliding Door Product Information
• 690 695 Series Sliding Door System 3-Part Spec
• 690 695 Series Sliding Door System CAD Drawings.dwg
• 690 695 Series Sliding Door System CAD Drawings.pdf
• 690 Series Sliding Door Installation Instructions
