CRL 6951D 695 Series Satin Anodized Sliding Door Kit with Softbrake System

CRL 6951D 695 Series Satin Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System with Fixed Panel offers a sophisticated solution for modern spaces, combining functionality with aesthetic appeal. This comprehensive kit is designed for use with 3/8" to 1/2" (10 to 12 mm) tempered glass and can accommodate doors weighing up to 330 pounds (150 kg), making it suitable for both residential and commercial applications. The sliding door kit features a generous 118" (3 m) track length, ensuring smooth operation and versatility in installation. With rollers that provide up to 1/4" (6 mm) of vertical adjustment, alignment is effortless after installation, promoting a seamless user experience. The kit includes everything needed for installation, from the CRL4933EXT track to the CRL6979A bottom channel and essential components like top hangers, roller stops, and a Softbrake kit that enhances safety and performance. Available in a satin anodized finish, this kit can also be customized with various architectural finishes through special orders. For professionals seeking a reliable and elegant door solution, the CRL 6951D is an excellent choice that balances style and durability.

695 Series Satin Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System with Fixed Panel

• Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
• Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
• Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid Door Alignment After Installation
• Track Length is 118" (3 m)
• Use Monolithic Tempered Glass

Resources

• 690 695 Series Grid System Installation Instructions
• 690 695 Series Sliding Door Product Information
• 690 695 Series Sliding Door System 3-Part Spec
• 690 695 Series Sliding Door System CAD Drawings.dwg
• 690 695 Series Sliding Door System CAD Drawings.pdf
• 695 Series Sliding Door Installation Instructions
