CRL 6951MBL 695 Series Matte Black Sliding Door Kit with Softbrake System

C.R. Laurence 6951MBL 695 Series Matte Black Sliding Door with Fixed Panel Kit with Softbrake Braking System offers a sleek and modern solution for your sliding door needs. Designed for use with 3/8" to 1/2" (10 to 12 mm) tempered glass, this kit accommodates doors weighing up to 330 pounds (150 kg), ensuring both durability and functionality. The 118" (3 m) track length provides ample space for a smooth sliding experience, while the Softbrake braking system ensures gentle and controlled door closure, enhancing safety and usability. Installation is made easier with rollers featuring up to 1/4" (6 mm) of vertical adjustment, allowing for precise door alignment post-installation. Included in the kit are essential components such as the CRL4931EXT track, CRL6979A bottom channel, glazing vinyl, CRL6939 top hangers, roller stops, a bottom guide, door edge guards, and a dropped ceiling adapter bracket. The matte black finish adds a contemporary touch, making it an ideal choice for modern interiors. For optimal performance, the minimum sliding panel width should be 34-1/4" (800 mm). This comprehensive kit is perfect for building professionals and knowledgeable homeowners seeking quality and style in sliding door systems.

695 Series Matte Black Sliding Door with Fixed Panel Kit with Softbrake Braking System

• Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
• Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
• Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
• Track Length is 118" (3 m)
• Use Monolithic Tempered Glass

Minimum sliding panel width of 34-1/4" (800 mm) for control in single or both directions.

Kit Contains:
• 118"(3m) of CRL4931EXT Track kit
• 118" (3m) of CRL6979A Bottom Channel
• Glazing Vinyl for 3/8" To 1/2" (10 To 12 mm) Glass
• 1 Set CRL6939 Top Hangers
• 1 Set CRL6942 Roller Stops
• 1 Each CRL2940 Bottom Guide
• 1 Set CRL2945 Door Edge Guards
• 1 Set CRL2929 Dropped Ceiling Adapter Bracket
• 1 Each CRL695SBK Softbrake Kit

Resources

• 690 695 Series Grid System Installation Instructions
• 690 695 Series Sliding Door Product Information
• 690 695 Series Sliding Door System 3-Part Spec
• 690 695 Series Sliding Door System CAD Drawings.dwg
• 690 695 Series Sliding Door System CAD Drawings.pdf
• 695 Series Sliding Door Installation Instructions
