CRL 695D 695 Series Satin Anodized Sliding Door Kit with Softbrake System
Images may not represent actual product and finish

CRL 695D 695 Series Satin Anodized Sliding Door Kit with Softbrake System

Your Price: $2,023.49
Retail Price:$2,422.48
Your Savings:$398.99(16%)
CRL 695D Sliding Door Kit features satin anodized finish, supports up to 330 lbs, and includes Softbrake system for smooth operation.
Part Number : CRL_695D
Availability: 18 In Stock
CRL 695D 695 Series Satin Anodized Sliding Door Kit with Softbrake System

C.R. Laurence 695 Series Satin Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System is designed for versatility and strength, accommodating 3/8" to 1/2" (10 to 12 mm) tempered glass doors weighing up to 330 pounds (150 kg). This robust kit includes a track length of 118" (3 m), ensuring a smooth, reliable operation ideal for both residential and commercial applications. The Softbrake braking system enhances user experience by providing controlled and gentle stops, reducing wear and tear on the door and hardware. With up to 1/4" (6 mm) of vertical adjustment on the rollers, the installation process allows for precise door alignment, ensuring a seamless fit in any architectural setting. Included in the kit are essential components such as the CRL4933EXT track, CRL6979A bottom channel, glazing vinyl, top hangers, roller stops, a bottom guide, door edge guards, and a dropped ceiling adapter bracket. The satin anodized finish not only adds to its aesthetic appeal but also ensures durability over time. For a minimum sliding panel width of 34-1/4" (800 mm), this sliding door kit embodies functionality and elegance. Choose C.R. Laurence for your glazing solutions and enjoy the perfect combination of quality and style.

695 Series Satin Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System

  • Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
  • Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
  • Rollers Have Up to 1/4" (6 mm) of Vertical Adjustments to Aid in Door Alignment After Installatiion
  • Track Length is 118" (3 m)
  • Use Monolithic Tempered Glass

CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the "Softbrake" braking system. All come with everything you need except the tempered glass and pull hardware. Kits are available in satin anodized, brushed stainless anodized, and matte black finishes with a special order option to clad or powder paint in many architectural finishes. Contact CRL Technical Sales for Commercial Products for kit selection or installation assistance.


Minimum sliding panel width of 34-1/4" (800 mm) for control in single or both directions.

Kit Contains:
  • 118"(3m) of CRL4933EXT Track kit
  • 118" (3m) of CRL6979A Bottom Channel
  • Glazing Vinyl for 3/8" To 1/2" (10 To 12 mm) Glass
  • 1 Set CRL6939 Top Hangers
  • 1 Set CRL6942 Roller Stops
  • 1 Each CRL2940 Bottom Guide
  • 1 Set CRL2945 Door Edge Guards
  • 1 Set CRL2929 Dropped Ceiling Adapter Bracket
  • 1 Each CRL695SBK Softbrake Kit

    Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.


    • Attributes

    Ship via: No UPS - Common Carrier Only

    Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov

    Finish/ Color:: Satin Anodized

    Glazing Thickness: 3/8 To 1/2 in. (10 To 12 mm)

    Shipping Limitations: No UPS - Common Carrier Only

    Track Length: 118 in. (3000 mm)
