CRL 695MBL 695 Series Matte Black Sliding Door Kit with Softbrake System

C.R. Laurence 695MBL 695 Series Matte Black Wall/Ceiling Mount Sliding Door Kit with Softbrake Braking System delivers a sleek and modern solution for your sliding door needs. Designed for 3/8" to 1/2" (10 to 12 mm) tempered glass, this robust kit can accommodate doors weighing up to 330 pounds (150 kg), ensuring durability and stability for heavy applications. The 118" (3 m) track provides a generous reach, while the Softbrake braking system offers a smooth and controlled door closure, enhancing user experience. With rollers featuring up to 1/4" (6 mm) of vertical adjustment, achieving precise door alignment is straightforward, making installation hassle-free. This comprehensive kit includes everything needed for installation-track, bottom channel, glazing vinyl, top hangers, roller stops, a bottom guide, door edge guards, and a dropped ceiling adapter bracket. Available in multiple finishes, including satin anodized, brushed stainless anodized, and the striking matte black, this sliding door kit can enhance any interior aesthetic. For professional-grade performance and style, the C.R. Laurence 695MBL Sliding Door Kit is the ideal choice for architects, builders, and discerning homeowners alike.

695 Series Matte Black Wall/Ceiling Mount Sliding Door Kit with Softbrake Braking System

• Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
• Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
• Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
• Track is 118" (3 m)
• Use Monolithic Tempered Glass

Resources

• 690 695 Series Grid System Installation Instructions
• 690 695 Series Sliding Door Product Information
• 690 695 Series Sliding Door System 3-Part Spec
• 690 695 Series Sliding Door System CAD Drawings.dwg
• 690 695 Series Sliding Door System CAD Drawings.pdf
• 695 Series Sliding Door Installation Instructions
