C.R. Laurence BEL090MBL Matte Black Bellagio Series Glass-to-Glass Bracket is the ideal solution for creating sleek and modern glass installations. Designed to accommodate 5/16" to 3/8" (8 to 10 mm) tempered glass, this bracket ensures a secure and stylish connection at a 90-degree angle. Its solid brass construction not only guarantees durability but also provides a premium aesthetic, enhanced by the sophisticated matte black finish. The bracket features tight gaps that effectively prevent water infiltration, making it perfect for shower enclosures and other wet areas. The snap-on covers cleverly conceal screws, maintaining a clean and polished appearance. Each panel is secured with two mounting screws, aligning seamlessly with other components in the Bellagio Series, including matching hinges. With a height of 2-15/16 in. (75 mm) and a leg length of 2-3/4 in. (69.9 mm), the BEL090MBL bracket supports a maximum door weight of 110 lbs and a maximum door width of 39 inches, catering to various design needs. Gaskets and mounting screws are included for easy installation, ensuring that your project progresses smoothly. Elevate your glass applications with the C.R. Laurence Bellagio Series Bracket, where style meets functionality.
Matte Black Bellagio Series Glass-to-Glass Bracket
CRL Bellagio Series 90 Degree Glass-to-Glass Bracket are designed to work with 5/16" to 3/8" (8 to 10 mm) thick glass. thick glass projects. The two mounting screws per panel matches the configuration of many of our most popular hinge series. Continuity of design is maintained by matching the look of the hinges used. They feature square corners and edges in several decorator finishes and are constructed of solid brass. Custom finishes are available on request by contacting CRL Technical Sales Shower Door Department.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Design Style: Concealed/Premium
Enclosure Type: Corner, Niche, Bathtub, Tailor Made Solutions
Finish/ Color:: Matte Black
Glass To Glass Angle: 90
Glazing Thickness: 5/16 in. To 3/8 in. (8 mm To 10 mm)
Height: 2-15/16 in. (75 mm)
Leg Length: 2-3/4 in. (69.9 mm)
Length: 2-3/4 in. (70 mm)
Material: Brass
Maximum Door Weight: 110
Maximum Door Width: 39
Mounting Type: Glass To Glass
Opening Style: Swing(side)
Series: Bellagio
Shipping Limitations: None
