CRL CD10X28BS Brushed Stainless 10"x28" Back-to-Back Offset Push-Pull Handle SetC.R. Laurence CD10X28BS Brushed Stainless 10" x 28" Back-to-Back Offset Combination Push and Pull Handle Set offers a perfect blend of functionality and aesthetic appeal for glass installations. Designed for use with 3/8" to 3/4" (10 to 19 mm) monolithic tempered glass, this handle set ensures robust support and accessibility. Constructed from 1" (25.4 mm) diameter stainless steel or brass tubing, the CD10X28BS is available in a variety of beautiful architectural finishes, allowing it to complement any design scheme. The set includes the necessary through-bolts for glass mounting, along with matching finish metal washers and rubber gaskets for a polished look and reliable performance. With mounting hole diameters of 5/8" (16 mm) and several center-to-center options, including 10" (254 mm) and 28" (711 mm), this handle set is versatile enough to meet diverse installation requirements. The offset design features a 3" (76 mm) center-to-center spacing, enhancing grip and usability. It is important to note that while stainless steel is resistant to corrosion, periodic maintenance is recommended to retain its factory finish. Elevate your space with the stylish and functional C.R. Laurence CD10X28BS handle set, a smart choice for any architectural project.
Brushed Stainless 10" x 28" Back-to-Back Offset Combination Push and Pull Handle Set
- For Use with 3/8" to 3/4" (10 to 19 mm) Glass
- 1" (25.4 mm) Diameter Stainless Steel or Brass Tubing
- Many Beautiful Architectural Finishes
- Use Monolithic Tempered Glass
This
CRL Glass Mounted Straight Push/Pull Handle Combination is available in two different sizes and many attractive architectural finishes.
SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) Glass
Construction: 1" (25 mm) Diameter
Stainless Steel or Brass Tubing
Glass Fabrication Required:
Three 5/8" (16 mm) Diameter Holes,
10" (254 mm) Center-to-Center
12" (305 mm) Center-to-Center
28" (711 mm) Center-to-Center
33" (838 mm) Center-to-Center
Offset: 3" (76 mm) Center-to-Center
Optional 1-1/4" (32 mm) Diameter
Available on Special Order
INCLUDES:
2 Each: Through-Bolts for Glass Mounting
4 Each: 1-1/4" (32 mm) Diameter Matching Finish Metal Washers and Rubber Gaskets
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Stainless Steel Advisory:
Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Attributes
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Diameter: 1 in. (25 mm)
Finish/ Color:: Brushed Stainless Steel
Glazing Thickness: 3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Hole Diameter: 5/8 in. (16 mm)
Mounting Type: Back-to-Back
Pull Mounting Center To Center: 10 in. (254 mm)
Push Mounting Center To Center: 28 in. (711 mm)
Shipping Limitations: None
Style Washer Diameter: 1-1/4 in. (32 mm)
Style Washers: Yes
