CRL CD10X33PS Polished Stainless 10"x33" Back-to-Back Offset Push-Pull Handle SetC.R. Laurence CD10X33PS Polished Stainless 10" x 33" Back-to-Back Offset Combination Push and Pull Handle Set seamlessly combines elegance and functionality for glass installations. Designed for use with 3/8" to 3/4" (10 to 19 mm) monolithic tempered glass, this handle set features robust 1" (25.4 mm) diameter stainless steel or brass tubing, ensuring durability and a refined aesthetic. Available in a polished stainless finish, the handles can also be customized in various architectural finishes to suit your design preferences. The set includes essential mounting hardware, such as through-bolts for glass mounting and matching finish metal washers with rubber gaskets, facilitating a straightforward installation process. With multiple mounting options, including center-to-center distances of 10" (254 mm) and 33" (838 mm), this handle set offers versatility tailored to your specific needs. The offset design provides an ergonomic grip, enhancing usability while maintaining a sleek profile. For optimal performance, periodic maintenance is recommended to preserve the factory finish of the stainless steel. Choose the C.R. Laurence CD10X33PS handle set for a stylish, practical solution that elevates any glass entrance or interior system.
Polished Stainless 10" x 33" Back-to-Back Offset Combination Push and Pull Handle Set
- For Use with 3/8" to 3/4" (10 to 19 mm) Glass
- 1" (25.4 mm) Diameter Stainless Steel or Brass Tubing
- Many Beautiful Architectural Finishes
- Use Monolithic Tempered Glass
This
CRL Glass Mounted Straight Push/Pull Handle Combination is available in two different sizes and many attractive architectural finishes.
SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) Glass
Construction: 1" (25 mm) Diameter
Stainless Steel or Brass Tubing
Glass Fabrication Required:
Three 5/8" (16 mm) Diameter Holes,
10" (254 mm) Center-to-Center
12" (305 mm) Center-to-Center
28" (711 mm) Center-to-Center
33" (838 mm) Center-to-Center
Offset: 3" (76 mm) Center-to-Center
Optional 1-1/4" (32 mm) Diameter
Available on Special Order
INCLUDES:
2 Each: Through-Bolts for Glass Mounting
4 Each: 1-1/4" (32 mm) Diameter Matching Finish Metal Washers and Rubber Gaskets
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Stainless Steel Advisory:
Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Attributes
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Diameter: 1-1/4 in. (32 mm)
Finish/ Color:: Polished Stainless Steel
Glazing Thickness: 3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Hole Diameter: 5/8 in. (16 mm)
Mounting Type: Back-to-Back
Pull Mounting Center To Center: 10 in. (254 mm)
Push Mounting Center To Center: 33 in. (838 mm)
Shipping Limitations: None
Style Washer Diameter: 1-1/4 in. (32 mm)
Style Washers: Yes
