CRL DK65BN Brushed Nickel 80" Side Jamb for CK/DK Cottage Series Sliders

CRL DK65BN Brushed Nickel 80" Side Jamb for CK/DK Cottage Series Sliders

C.R. Laurence DK65BN Brushed Nickel 80" Side Jamb for CK/DK Cottage Series Sliders offers a robust solution for enhancing your shower enclosure. This side jamb is specifically designed for use against vertical walls in "DK" Series slider applications, providing stability and support. Crafted from high-quality aluminum with a brushed nickel finish, it seamlessly complements various design aesthetics, matching well with other finishes like Brite Anodized, Brite Gold Anodized, and Oil Rubbed Bronze. The DK65BN allows for versatile configurations, enabling you to create customized shower setups or add additional panels for a more expansive design. Whether you are a professional builder or a knowledgeable homeowner, you can either assemble your enclosure from stock components or send us your design for a tailored kit, complete with installation instructions. This product accommodates monolithic tempered glass, with options for 1/4" or 3/8" thickness. The recommended maximum sizes for sliding glass panels ensure you can achieve the desired look without compromising on quality. Note that all fixed glass panels must be 3/8" thick. With its thoughtful design and elegant finish, the C.R. Laurence DK65BN Side Jamb is a perfect addition to any modern shower renovation project.

Brushed Nickel 80" Side Jamb for CK/DK Cottage Series Sliders

• Side Jamb is Used Against the Vertical Wall in "DK" Series Slider Applications
• Brite Anodized, Brite Gold Anodized, Brushed Nickel, and Oil Rubbed Bronze Finishes to Match Our Kits
• Do It Yourself, or You Can Send Us a Drawing to Customize a Unit for You
• Use Monolithic Tempered Glass

CRL Side Jamb for CK/DK Cottage Series Sliders components add versatility to our Frameless Sliding Shower Door Kits, and allows you the option of adding additional panels to create a designer enclosure, or simply construct your own sliding unit by combining the various parts. Stock lengths of Headers, Header Fillers, Bottom Sills, Sidelite Sills, Side Jambs, Top Hangers and other accessory items complete the selection.


Use these components to build the enclosure you require, or we can assist with your design. Email or fax us a drawing (with dimensions) of the shower opening and we will put together a customized kit for you that will include everything you will need (except the glass and the silicone). Installation instructions are included in each custom kit.

NOTE: All fixed panels of glass must be 3/8" (10 mm) thick.

SPECIFICATIONS:
Material: Extrusions (Aluminum), Towel Bar (Brass Tubing), Knob (Solid Brass)
Glass Thickness: 1/4" or 3/8" (6 or 10 mm) (Glass not included)
Recommended Maximum Slider Sizes: 1/4" (6 mm) Glass: 60" W x 72" H (1.52 x 1.83 m) or 72" W x 60" H (1.83 x 1.52 m); 3/8" (10 mm) Glass: 72" W x 80" H (1.83 x 2.03 m)
Glass Fabrication: Towel Bar – Two 1/2" (12 mm) Diameter Holes, 24" (610 mm) Center-to-Center; Knob – One 1/2" (12 mm) Diameter Hole; Top Hangers – Four 1/2" (12 mm) Diameter Holes (two per glass panel)


Product Warning:

Hardware Package includes Corners and Header Bracket required to convert Inline Shower Door Kit into an angled enclosure when used with the appropriate extrusions from above. Must be ordered separately. Polycarbonates are translucent in color.
