CRL GR20SB C260 Satin Brass 2" Cap Rail for 1/2" Glass - 120" Length

CRL GR20SB C260 Satin Brass 2" Cap Rail for 1/2" Glass - 120" Length

C.R. Laurence GR20SB C260 Alloy Satin Brass 2" Premium Cap Rail for 1/2" Glass - 120" offers exceptional durability and aesthetic appeal, making it a top choice for any architectural project. This cap rail is meticulously manufactured using a unique Bump-Forming process, which ensures high precision, consistency, and strength without the stress and spring back often found in roll-formed products. Measuring 120" (3.05 m) in length and crafted from satin brass, it maintains uniform diameters for smooth transitions at splices, corners, and end caps. Designed for versatility, this cap rail connects seamlessly to a variety of fabricated corners and end caps, and it can be cut to size or custom fabricated to meet your project needs. The internal channel is welded to enhance strength and stability during fabrication. For secure connections, utilizing C.R. Laurence's Cat. No. 32629 Metal Contact Cement is recommended. Compatible with 1/2" (12 mm) and 5/8" (16 mm) glass, this premium cap rail ensures a secure installation when paired with the appropriate sealing products. Please note that while satin brass is durable, it is prone to oxidation, which may lead to tarnishing over time. Elevate your architectural designs with the reliability and elegance of C.R. Laurence's Premium Cap Rail.

C260 Alloy Satin Brass 2" Premium Cap Rail for 1/2" Glass - 120"

• Bump-Formed and Welded 120" (3.05 m) and 168" (4.27 m) Stock Lengths are Available in Seven Diameters from 1-1/2" (38.1 mm) to 4" (101.6 mm)
• Four Architectural Finishes
• Connects to a Variety of Fabricated Corners and End Caps
• Cut to Size or Custom Fabricated Lengths Also Available
• Use Sleeve No. GR20CSB

CRL's Premium Cap Rails are manufactured using a unique process known as Bump-Forming that ensures accuracy, consistency, and high quality. Unlike roll-formed cap rails, CRL's Bump-Formed Premium Cap Rails do not contain the stress and spring back associated with the roll-formed product. Welds on both sides of the channel add strength and stability to the Cap Rail. This results in a Cap Rail with tighter tolerances, consistent radius, and the ability to fit into welded corners without twist or discoloration. Put simply, it means this is the best product in the market place.


All CRL Premium Cap Rail are formed using precision tooling to maintain uniform diameters, allowing for smooth hairline transitions at splices, corners, and end caps. The internal channel is welded in place to increase strength and stability for fabrication. Use of our Cat. No. 32629 Metal Contact Cement is required to achieve a secure and permanent bond at all connections. Use Connector Sleeves to connect Cap Rails. Sold in 120" (3.05 m) lengths.

NOTE: When used with 1/2" (12 mm) glass, Cat. No. GR5PV Cap Rail Vinyl and 95CBL Silicone should be used to secure the glass. When used with 5/8" (16 mm) glass, secure with 95CBL Silicone Sealant and Shims. Please contact CRL Technical Sales for more information or for a quote.

Use of our 32629 Metal Contact Cement is required to achieve a secure and permanent bond at all connections.

Use the Connector Sleeves to connect Cap Rails. NOTE:When used with 3/4" (19 mm) glass, 95CBL Silicone and shims should be used to secure the glass. All CRL Premium Cap Railings are stainless alloy 304. Stainless alloy 316 is available on special order. Please contact CRL Technical Sales for more information or for a quote.

Brass Finish Advisory:
