CRL GR25HBS Brushed Stainless 90 Corner for 1/2" or 5/8" Glass Cap Railing, 2-1/2" DiameterC.R. Laurence GR25HBS Brushed Stainless 2-1/2" Diameter 90 Degree Horizontal Corner for 1/2" or 5/8" Glass Cap Railing offers a sleek, modern solution for your railing needs. Designed for effortless installation, this corner is welded, finished, and ready to use, ensuring a clean and professional appearance in any setting. Crafted from premium stainless steel, the GR25HBS features a brushed finish that not only enhances its aesthetic appeal but also provides durability and resistance to corrosion. This horizontal corner accommodates both 1/2" (12 mm) and 5/8" (16 mm) thick glass, allowing for hairline joint assemblies when paired with CRL Cap Rail straight lengths. To ensure a secure and permanent bond, the use of CRL's Cat. No. 32629 Metal Contact Cement is required. Each unit requires two connector sleeves for optimal performance, which are sold separately. Available in four architectural finishes, the GR25HBS is fabricated to match CRL's Premium Cap Rail, allowing for seamless integration into your projects. Keep in mind that periodic maintenance is recommended to preserve its factory finish. For further details or quotes, reach out to CRL Technical Sales. Transform your glass railing systems with the reliability and elegance of this expertly designed corner.
Brushed Stainless 2-1/2" Diameter 90 Degree Horizontal Corner for 1/2" or 5/8" Glass Cap Railing
- Welded, Finished, and Ready-to-Install
- Four Architectural Finishes
- Requires Two Connector Sleeves (Not Included)
Interior slip-fit Horizontal Corners for 1/2" (12 mm) or 5/8" (16 mm) thick glass allow for hairline joint assemblies with straight lengths of
CRL Cap Rail. Use of our Cat. No. 32629 Metal Contact Cement is required to achieve a secure and permanent bond. Two Connector Sleeves are required for use with each corner.
Each Horizontal Corner is fabricated, finished, and individually packed. All of our stainless and brass corners are fabricated from CRL Premium Cap Rail, and are welded and finished to match. Standard stainless alloy is 304. Stainless alloy 316 is available on special order. For brass, alloy 260 is standard.
Please contact
CRL Technical Sales for more information or a quote.
NOTE: With the exception of the GR15 Series Cap Rail Corners, when used with 1/2" (12 mm) glass, our GR5PV Cap Rail Vinyl and 95CBL Silicone should be used to secure the glass. When using GR15 Series Cap Rail Corners or 5/8" (16 mm) glass, use 95CBL Silicone and shims only to secure the glass.
Product Warning:
When used with 1/2" (12 mm) glass, our GR5PV Cap Rail Vinyl and 95CBL Silicone should be used to secure the glass. When used with 5/8" (16 mm) glass, secure with shims and 95CBL Silicone.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Stainless Steel Advisory:
Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Attributes
Angle: 90
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Diameter: 2-1/2 in. (64 mm)
Finish/ Color:: Brushed Stainless Steel
Material: Stainless Steel
Shipping Limitations: None
