CRL P190SSB Satin Brass Pinnacle Prima Wall Mount Bracket

C.R. Laurence P190SSB Satin Brass Pinnacle and Prima Series Wall Mount Bracket offers a sophisticated solution for securely mounting glass panels in various applications. Designed specifically for 5/16" to 1/2" (8 to 12 mm) thick monolithic tempered glass, this wall mount bracket is an ideal choice for creating seamless, elegant glass structures. Constructed from solid brass, the P190SSB ensures durability while providing a refined aesthetic. Its beveled clamps are compatible with the Pinnacle, Prima, Senior Prima, Cologne, and Estate Series hinges, allowing for a cohesive design throughout your project. The rounded corners and beveled edges enhance the overall visual appeal, making it suitable for both residential and commercial settings. In addition to its primary function, this versatile bracket can also serve as a horizontal shelf support, expanding its utility. Each bracket includes gaskets and mounting screws for easy installation, requiring two 3/4" (19 mm) holes per panel for secure attachment. While the satin brass finish adds a touch of luxury, it’s important to note that brass can be prone to oxidation, leading to a tarnished appearance over time. For those seeking a blend of functionality and style, the C.R. Laurence P190SSB bracket is a perfect choice for any glazing project.

Satin Brass Pinnacle and Prima Series Wall Mount Bracket

• Beveled Clamps to Match Pinnacle, Prima, Senior Prima, Cologne, and Estate Series Hinges
• For 5/16" to 1/2" (8 to 12 mm) Glass
• Solid Brass
• Use Monolithic Tempered Glass

CRL Prima Series Wall Mount Glass Brackets are designed to work with 5/16" to 1/2" (8 to 12 mm) thick glass. Can also be used as a horizontal shelf bracket. The Prima Wall Brackets have the identical configuration as the Prima and Pinnacle Hinges which will help provide continuity of design. They feature rounded corners and beveled edges in several decorator finishes and are constructed of solid brass. Custom finishes are available upon request.

P612** replacement screws

Brass Finish Advisory:
