CRL P536CPS Polished Stainless 180 P5 Series Center Post Railing Kit

C.R. Laurence P536CPS Polished Stainless 180 Degree Center P5 Series Post Railing Kit is expertly crafted for both commercial and residential applications, ensuring compliance with guard rail code standards. Designed to accommodate glass panels ranging from 1/2" (12 mm) to 1" (25 mm) in thickness, this kit requires glass fabrication for optimal installation. The robust P5 Posts, constructed from flat bar stainless steel, are engineered to support 1-1/4" (32 mm) or 1-1/2" (38 mm) diameter Schedule 40 handrail tubing. Available in standard heights of 36" (914 mm) and 42" (1067 mm), custom height options provide flexibility to fit various architectural needs. This kit is offered in two standard stainless finishes, with custom powder paint finishes available to match your design aesthetic. It is important to note that the P5 Series Post Kits are sold without glass attachment fittings, which must be purchased separately. While the polished stainless steel offers a sleek and modern look, regular maintenance is recommended to preserve its factory finish, as stainless steel is resistant but not entirely stain-proof. Enhance your space with the durability and style of the C.R. Laurence P536CPS Railing Kit, a trusted choice for discerning builders and homeowners alike.

Polished Stainless 180 Degree Center P5 Series Post Railing Kit

• For Use with 1/2" (12 mm) to 1" (25 mm) Thick Panels
• Glass Fabrication Required
• Meets or Exceeds Code Standards
• Post Supports 1-1/4" or 1-1/2" (32 or 38.1 mm) Diameter Schedule 40 Handrail Tubing
• Standard Post Heights are 36" (914 mm) and 42" (1067 mm), with Custom Heights Available
• Two Standard Stainless Finishes, with Custom Powder Paint Finishes Also Available

Stainless Steel Advisory:

Resources

• Architectural Glass Railing Systems and Hardware Catalog
• Architectural Glass Railing Systems and Hardware Catalog
• CRL Stainless Steel Disclaimer
• P-Series Post Railing Installation Instructions
• P-Series Post Railing Specification
• P-Series Post Railing System Quote Request Form
• P-Series Post Railing Systems Engineering Report 01-21-2025
• P-Series Post Railing Systems Engineering Report 04-03-2019
• P5 Series Post Railing System CAD Drawings.dwg
• P5 Series Post Railing System CAD Drawings.pdf
• Windscreen and Pool Fencing Systems Product Information
