C.R. Laurence PH10ELA Satin Anodized LH North American Bottom Door Patch Fitting is designed to provide robust support and seamless integration for 3/8" or 1/2" (10 or 12 mm) tempered glass doors. This high-quality fitting is perfect for Herculite™+ style doors, ensuring both durability and aesthetic appeal. With a pivot setback of 2-3/4" (70 mm), it offers reliable functionality while maintaining a sleek, modern look. This bottom door patch fitting includes essential components: one AMR201 door patch, and both left and right bottom door patches (1NT305L and 1NT305R), all crafted to work seamlessly with your glazing project. The required glass fabrication includes a 3/4" (19 mm) diameter hole and corner notch, with a template available at crlaurence.com for easy installation. Engineered for left-handed operation, the satin anodized finish gives it a contemporary flair, making it an ideal choice for both residential and commercial applications. Notably, it complies with GANA guidelines for maximum door size, ensuring safety and reliability. Elevate your glass door systems with the C.R. Laurence PH10ELA fitting, where form meets function in architectural design.
Satin Anodized LH North American Bottom Door Patch Fitting
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Satin Anodized
Glazing Thickness: 3/8 in., 1/2 in. (10 mm, 12 mm)
Handing: Left Hand
Insert Type: 1NT305L
Pivot Setback: 2-3/4
Series: North American
Shipping Limitations: None
Type: Bottom
With Insert: Yes
