C.R. Laurence PH10ERA Satin Anodized RH North American Bottom Door Patch Fitting is designed to elevate the functionality and aesthetic of your Herculite™+ style doors. Engineered for use with 3/8" or 1/2" (10 or 12 mm) tempered glass, this bottom door patch fitting offers a robust solution for a variety of applications. Featuring a 2-3/4" (70 mm) pivot setback, the PH10ERA is tailored for seamless installation and operation. It includes essential components such as one AMR201 door patch, and both left and right bottom door patches (1NT305L and 1NT305R), ensuring that you have everything you need for a complete setup. The product requires a glass fabrication of a 3/4" (19 mm) diameter hole and corner notch for optimal performance, with a template available at crlaurence.com for your convenience. Crafted with a satin anodized finish, this fitting not only offers durability but also enhances the visual appeal of your installation. Please note that adherence to GANA Guidelines is recommended for determining the maximum door size when using this product. Trust C.R. Laurence for quality and reliability in architectural hardware solutions.
Satin Anodized RH North American Bottom Door Patch Fitting
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Satin Anodized
Glazing Thickness: 3/8 in., 1/2 in. (10 mm, 12 mm)
Handing: Right Hand
Insert Type: 1NT305R
Pivot Setback: 2-3/4
Series: North American
Shipping Limitations: None
Type: Bottom
With Insert: Yes
