C.R. Laurence PH10ERBS Brushed Stainless RH North American Bottom Door Patch Fitting is engineered for optimal performance and durability, making it an essential component for any modern glass entrance system. Compatible with 3/8" or 1/2" (10 or 12 mm) tempered glass, this product features a 2-3/4" (70 mm) pivot setback, specifically designed for Herculite™+ style doors. The fitting requires a glass fabrication that includes a 3/4" (19 mm) diameter hole and a corner notch, with a detailed template available at crlaurence.com to streamline installation. Each package includes one AMR201 door patch and both left and right bottom door patches (1NT305L and 1NT305R), along with insert gaskets suitable for 3/8" or 1/2" glass. Crafted from brushed stainless steel, the PH10ERBS offers a sleek, professional finish that enhances the aesthetic of any space. While stainless steel is resistant to corrosion, routine maintenance is recommended to preserve its factory appearance. This product meets GANA guidelines regarding maximum door sizes, ensuring reliability and safety in high-traffic areas. With no shipping limitations, the PH10ERBS is a versatile and practical choice for your glazing needs.
Brushed Stainless RH North American Bottom Door Patch Fitting
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Brushed Stainless Steel
Glazing Thickness: 3/8 in., 1/2 in. (10 mm, 12 mm)
Handing: Right Hand
Insert Type: 1NT305R
Pivot Setback: 2-3/4
Series: North American
Shipping Limitations: None
Type: Bottom
With Insert: Yes
