C.R. Laurence PH11ERA Satin Anodized RH European Bottom Door Patch Fitting is designed for use with 3/8" or 1/2" (10 or 12 mm) tempered glass, making it an ideal choice for Herculite™+ style doors. This robust patch fitting features a pivot setback of 2-9/16" (65 mm), ensuring a seamless integration with your door system while maintaining aesthetic appeal. The package includes one AMR201 door patch, along with left and right bottom door patch inserts (1NT305L and 1NT305R), as well as gaskets suitable for both 3/8" and 1/2" glass. Proper glass fabrication is required, which includes a 3/4" (19 mm) diameter hole and corner notch. A template is conveniently available at crlaurence.com to aid in precise installations. The satin anodized finish not only enhances durability but also adds a modern touch to any architectural project. This product adheres to GANA guidelines, ensuring safety and reliability in its application. With no shipping limitations and the ability to ship via UPS, the PH11ERA fitting is both accessible and efficient for building professionals and knowledgeable homeowners alike. Elevate your glass installations with the reliability and style of C.R. Laurence.
Satin Anodized RH European Bottom Door Patch Fitting
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Finish/ Color:: Satin Anodized
Glazing Thickness: 3/8 in., 1/2 in. (10 mm, 12 mm)
Handing: Right Hand
Insert Type: 1NT305R
Pivot Setback: 2-9/16
Series: European
Shipping Limitations: None
Type: Bottom
With Insert: Yes
