CRL S0GC910RB Oil Rubbed Bronze Adjustable Sleeve Over Glass Clamp

Your Price: $45.43

Retail Price:$54.38

Your Savings:$8.95(16%)

The CRL S0GC910RB Oil Rubbed Bronze Adjustable Glass Clamp securely holds 5/16" to 1/2" thick tempered glass at various angles.

Part Number : CRL_S0GC910RB

Availability: 229 In Stock

Quantity

Description

CRL S0GC910RB Oil Rubbed Bronze Adjustable Sleeve Over Glass Clamp

C.R. Laurence S0GC910RB Oil Rubbed Bronze Adjustable "Sleeve Over" Glass Clamp offers an elegant and robust solution for securing glass panels ranging from 5/16" to 1/2" (8 to 12 mm) thick. Crafted from solid brass, this clamp not only enhances durability but also provides an appealing oil-rubbed bronze finish that complements a variety of architectural styles. Designed to effectively manage shear forces, the S0GC910RB ensures that glass panels remain securely in position while the silicone sealant cures. This dual functionality is invaluable, as the sealant not only bonds the panels together but also prevents water leakage, enhancing the longevity of your installation. The adjustable design allows for a versatile range of angles, from 90 to 180 degrees, making it suitable for both square cut and mitered panels. Installation is straightforward, with no special glass fabrication required. The clamps tighten securely using nylon-tipped Allen set screws, and each unit includes gaskets for a snug fit. However, it is essential to note that these clamps are not a substitute for headers or support bars, ensuring safe and reliable performance in your glazing projects. For a blend of style and functionality, the C.R. Laurence S0GC910RB is an excellent choice for any glass installation.

Oil Rubbed Bronze Adjustable "Sleeve Over" Glass Clamp

For 5/16" to 1/2" (8 to 12 mm) Thick Glass
Use Monolithic Tempered Glass
Adjustable from 90 to 180 Degrees
Solid Brass
Assists with Shear Forces
Holds Glass Panels in Position While Sealant Cures

CRL Sleeve Over Glass Clamps are designed to provide a mechanical fastener to cover the shear forces placed on the glass panels. No special fabrication of the glass is required. Can also be used to secure the glass panels in position while the applied silicone sealant in the joint cures (the silicone sealant glues the glass panels together, prevents water leakage, and provides the pull strength to keep the panels from separating). Clamps are secured in place by nylon tipped Allen set screws.

SPECIFICATIONS:
Material: Solid Brass
Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
No Glass Fabrication Required (Clamps tighten using nylon tipped Allen screws).
Includes: Gaskets

NOTE: These Clamps are not designed to take the place of Headers or a Support Bar. Contact CRL Frameless Shower Technical Sales Department for more details. Can be used on both square cut or mitered panels.

Product Warning:

These Clamps are not designed to take the place of Headers or a Support Bar.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Attributes

Adjustable: Yes

Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov

Finish/ Color:: Oil Rubbed Bronze

Glazing Thickness: 5/16 in. To 1/2 in. (8 mm To 12 mm)

Material: Brass

Mounting Type: Glass To Glass

Shipping Limitations: None
