CRL SH3648XXA Satin Anodized Sharyn 36"x48" Frameless Pass-ThruC.R. Laurence SH3648XXA Satin Anodized Sharyn 36" x 48" XX Frameless Pass-Thru offers a sleek, modern solution for service openings, transforming traditional pass-thru windows into a sophisticated architectural feature. The frameless design enhances visual appeal, while the innovative no-hole top hung clamp-on roller assemblies provide height adjustability of approximately 3/16" (5 mm) to accommodate varying field conditions. With a double track header that discreetly conceals roller assemblies, this pass-thru window eliminates the need for unattractive valance covers. It features a configuration of two sliding panels on the clerk side, ensuring smooth operation and easy access. The window is available in a range of finishes, including Brite Anodized, Satin Anodized, and Dark Bronze, allowing for customization to match any interior aesthetic. Stock models come with 1/4" (6 mm) clear tempered glass, complete with two top hung roller assemblies, bottom guides, and a push button lock for secure closure. An optional fixed lite header insert is available for added functionality. Ideal for interior use, the SH3648XXA is a perfect choice for hospitality settings, service counters, or display areas, enhancing both form and function.
Satin Anodized Sharyn 36" x 48" XX Frameless Pass-Thru
- Modern "Frameless" Appearance as Opposed to Traditional Framed Pass-Thru Windows
- No-Hole Top Hung Clamp-On Roller Assemblies Allow Height Adjustability
- Double Track Header has Side Walls that Hide Roller Assemblies
- Optional Fixed Lite Header Insert
- Available in Brite Anodized, Satin Anodized, and Dark Bronze Finishes
- Sized to Fit Opening 36" W x 48" H
- XX Clerkside (X=Sliding Panel, X=Sliding Panel)
- View: Clerk Side View
The CRL Sharyn Frameless Pass-Thru Window will bring a modern appearance to what has been a traditional looking world of pass-thru windows. The "No Hole" Clamp-On Assemblies match the Header finishes, and allow height adjustment of approximately 3/16" (5 mm) that may be required due to field conditions. The Double Track Header has side walls that discreetly hide the Roller Assemblies, thus eliminating the need for unsightly valance covers. The Sharyn "Frameless" Pass-Thru Window is offered in three different two panel configurations of sliding and fixed panels to accommodate most any service condition. An optional Fixed Lite Header Insert is for the fixed side panel.A Thru-Glass Mounted Keyed Lock or Push Button Lock can be ordered separately for Custom Windows. The Push Button Lock is included on the stock window. Rubber Bumpers are included in each kit to assure soft closing of the window. 36" x 48" (.914m x 1.22 m) 1/4" (6 mm) pre-glazed stock models are available when a quick solution is required to complete your job, or "Quick-Fab" Custom Windows are also available. Custom windows are available with 1/4" (6 mm) clear tempered glass, or unglazed.
STOCK WINDOWS INCLUDE: One Double Track Header, 1/4" (6 mm) Clear Tempered Glass, Two Top Hung Roller Assemblies per Sliding Panel, Three Bottom Guides, One Push Button Lock with Two Strikes, and Eight Bumpers.
NOTE: Fixed Lite Models Include One Fixed Lite Header Insert and Bottom Channel.
Header cut at 35-15/16". Height at 48". Bottom guide included.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Attributes
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Configuration: XX
Deal Tray Included: No
Finish/ Color:: Satin Anodized
Frame Depth: 2 in. (50.8 mm)
Glazing Type: 1/4 in. (6 mm) Clear Tempered Glass
Handle Type: Self Latching
Height: 48 in. (1219.2 mm)
Latch Type: LK49
Material: Aluminum
Shipping Limitations: None
Usage: Interior
Width: 36 in. (914.4 mm)
