C.R. Laurence SH3648XXBRZ Duranodic Bronze Sharyn 36" x 48" XX Frameless Pass-Thru Window redefines the conventional pass-thru with its sleek, modern frameless design. This innovative window features a double track header with side walls that discreetly conceal the roller assemblies, eliminating the need for unattractive valance covers. The no-hole clamp-on roller assemblies provide an adjustable height of approximately 3/16" (5 mm), accommodating field conditions effortlessly. Designed for functionality, the Sharyn model offers a versatile XX configuration with two sliding panels, ensuring fluid access between spaces. It is available in a rich Duranodic Bronze finish, as well as Brite and Satin Anodized options, enhancing the aesthetic appeal of any interior setting. Each stock window includes high-quality 1/4" (6 mm) clear tempered glass, two top hung roller assemblies per sliding panel, and rubber bumpers for a soft closing mechanism. For added security, a push button lock is included, with an optional thru-glass mounted keyed lock available. The Sharyn Frameless Pass-Thru Window is sized to fit openings of 36" W x 48" H, making it an ideal choice for both commercial and residential applications, ensuring style and functionality in one elegant package.
Duranodic Bronze Sharyn 36" x 48" XX Frameless Pass-Thru
The CRL Sharyn Frameless Pass-Thru Window will bring a modern appearance to what has been a traditional looking world of pass-thru windows. The "No Hole" Clamp-On Assemblies match the Header finishes, and allow height adjustment of approximately 3/16" (5 mm) that may be required due to field conditions. The Double Track Header has side walls that discreetly hide the Roller Assemblies, thus eliminating the need for unsightly valance covers. The Sharyn "Frameless" Pass-Thru Window is offered in three different two panel configurations of sliding and fixed panels to accommodate most any service condition. An optional Fixed Lite Header Insert is for the fixed side panel.A Thru-Glass Mounted Keyed Lock or Push Button Lock can be ordered separately for Custom Windows. The Push Button Lock is included on the stock window. Rubber Bumpers are included in each kit to assure soft closing of the window. 36" x 48" (.914m x 1.22 m) 1/4" (6 mm) pre-glazed stock models are available when a quick solution is required to complete your job, or "Quick-Fab" Custom Windows are also available. Custom windows are available with 1/4" (6 mm) clear tempered glass, or unglazed.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Configuration: XX
Deal Tray Included: No
Finish/ Color:: Duranodic Bronze
Frame Depth: 2 in. (50.8 mm)
Glazing Type: 1/4 in. (6 mm) Clear Tempered Glass
Handle Type: Self Latching
Height: 48 in. (1219.2 mm)
Latch Type: LK49
Material: Aluminum
Shipping Limitations: None
Usage: Interior
Width: 36 in. (914.4 mm)
