CRL SUP20BN51 Brushed Nickel 51" Sleeve-Over Glass-To-Glass Support Bar provides robust support for fixed glass panels in enclosures that do not extend to the ceiling. Crafted from a durable 3/4" (19 mm) diameter tubular brass bar with solid brass end caps, this support bar is designed for use with tempered safety glass ranging from 3/8" to 1/2" (10 to 12 mm) thick. The innovative design eliminates the need for hole drilling or cut-outs, making installation straightforward and efficient. Each bar features a swiveling U-shaped receptacle on both ends to secure the glass panels, while nylon-tipped set screws prevent any glass-to-metal contact, ensuring both stability and safety. With a standard length of 51" (1.3 m), the bar can be easily cut to fit specific requirements, providing versatility and customization for various projects. Included in the package are all the necessary mounting hardware, ensuring you have everything needed for a seamless installation. Finished in brushed nickel, this support bar not only enhances functionality but also adds a contemporary touch to any space. Choose the CRL SUP20BN51 for a reliable and stylish solution to your glass panel support needs.
Brushed Nickel 51" Sleeve-Over Glass-To-Glass Support Bar for 3/8" to 1/2" Thick Glass
This CRL Fixed Panel Support Bar stabilize fixed panels of glass in enclosures that do not go all the way up to the ceiling. The Glass-to-Glass Bar has a solid brass end cap with a swiveling U-shaped receptacle on both sides to secure each fixed panel. Nylon-tipped set screws secure the glass and prevent glass-to-metal contact. No holes or cut-outs required. Stock Bars are 51" (1.28 m) in length. Simply cut-to-size required.
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
Ship via: No UPS - Common Carrier Only
Compliance and Restrictions: Warning Reproductive Harm - www.p65warnings.ca.gov
Construction: Tubular
Diameter: 3/4 in. (19 mm)
Finish/ Color:: Brushed Nickel
Glazing Thickness: 3/8 in. To 1/2 in. (10 mm To 12 mm)
Length: 51 in. (1295 mm)
Material: Brass
Shipping Limitations: UPS Oversize Rate
