CRL TND92571P0 U.S. Aluminum KYNAR 900 Terrace Swing-Out Door Pair

CRL TND92571P0 - U.S. Aluminum Custom KYNAR Paint Series 900 Terrace Door Pair Swing Out combines functionality with contemporary design. This impressive entrance system features a thermally broken door and frame, ensuring energy efficiency and comfort in any climate. Pre-assembled for your convenience, this door is ready to install, saving you valuable time on-site. Designed with durability in mind, the door is constructed with a robust 2-1/4" thick frame and 3.75" stiles, top, and bottom rails. It accommodates 1" insulated glass, providing excellent insulation and aesthetics. The five-knuckle hinges, equipped with non-removable pins, enhance security and longevity, while the advanced seven-point locking hardware ensures peace of mind. This terrace door system is finished in a Custom Kynar paint, offering a sleek, modern look that can complement any architectural style. With the standard features of butt hinge hardware and glass stops for tempered glass, it’s tailored to meet the demands of professional builders and discerning homeowners alike. Please note that shipping is via common carrier only, ensuring your order arrives safely. Elevate your building project with the reliability and elegance of the CRL Series 900 Terrace Entrance.

-U.S. Aluminum Custom KYNAR Paint Series 900 Terrace Door Pair Swing Out

• Thermally Broken Door and Frame
• Glass Stops for 1" Insulated Glass
• Door and Frame Shipped Assembled
• 1-1/2 Pair Five Knuckle Hinges with Non Removable Pins
• Seven-Point Locking Hardware

Resources

• AAMA Test Report Expiration Statement
• AAMA Test Report Expiration Statement
• Entrance Hardware Brochure
• Entrance Hardware Brochure
• Glazing Unit Quote Request Form
• Glazing Unit Quote Request Form
• Institutional Project Case Studies
• Institutional Project Case Studies
• Series 900 - Terrace Door In-Swing Test Report D6387.01-301-47
• Series 900 - Terrace Door Out-Swing Test Report D6385.01-301-47
• Series 900 925 Patio Door Adjustable Pivot Hinge - Field Replacement Installation Instructions
• Series 900 Double Door In-Swing Test Report D6386.01-301-47
• Series 900 Out-Swing ASTM E 90 Sound Transmission Loss Test Report 63137.01-113-11
• Series 900 Out-Swing Doube ASTM E 90 Sound Transmission Loss Test Report 63136.01-113-11
• Series 900 Out-Swing Pair AAMA WDMA CSA 101 I.S.2 A440-05 Test Report 63401.01-44
• Series 900 Terrace BIM.pdf
• Series 900 Terrace BIM.rvt
• Series 900 Terrace Door - Double Inswing Glazing Chart
• Series 900 Terrace Door - Double Outswing Glazing Chart
• Series 900 Terrace Door - Sidelite Glazing Chart
• Series 900 Terrace Door - Single Inswing Glazing Chart
• Series 900 Terrace Door - Single Outswing Glazing Chart
• Series 900 Terrace Door - Transom Glazing Chart
• Series 900 Terrace Door Installation Instructions
• Series 900 Terrace Door Numbering Key - Inswing and Outswing Doors
• Series 900 Terrace Door Outswing Door Quote Request Form
• Series 900 Terrace Door Outswing and Inswing Doors Standard Sill Quote Request Form
• Series 900 Terrace Door Product Information
• Series 900 Terrace Door Series 925 Patio Door - Sidelite Fixed Lite and Transom Lite Frames Quote Request Form
• Series 900 Terrace Door Series 925 Patio Door and D900 Impact Resistant Terrace Door Numbering Key - Hardware Selection
• Series 900 Terrace Door Series CAD Drawings.dwg
• Series 900 Terrace Door Series CAD Drawings.pdf
• Series 900 Terrace Door Swinging Door with Frame AAMA 1503-09 Thermal Performance Test Report
• Series 900 Terrace Door Swinging Door with Frame NFRC 102-2010 Thermal Performance Test Report
• Series 900 Terrace Door and Series 925 Patio Door - Sidelite Assembly Installation Instructions
• Series 900 Terrace Door with Low Profile Threshold Product Information
• Series 900 with Low proofile Threshold Report I3839.01-303-47 R4
• Series D900 Outswing - .19 Mono X .44 Lam - Acoustical Performance ASTM E90 - H9895.01-303-11
• USAL14 The Storefront Store Catalog
• USAL14 The Storefront Store Catalog
• USAL15 Curtain Walls Catalog
• USAL15 Curtain Walls Catalog
